Power Supply, LIAN LI, SP750, SFX, PC, 100 - 240 V, 750 W, G9P.SP0750G.B000.EU
Product reference: 2-4718466018328

Power Supply, LIAN LI, SP750, SFX, PC, 100 - 240 V, 750 W, G9P.SP0750G.B000.EU

Product reference: 2-4718466018328
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
121,68 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Блок живлення SFX Lian Li 80 PLUS Gold 750W Black (G9P.SP0750G.B000.EU)



PERFORMANCE SFX FORM FACTOR POWER SUPPLY

The SP V2 Gold is a stylish high-performance PSU that perfectly fits small-form-factor PCs while supporting power-hungry components.



AVAILABLE IN TWO COLORS & TWO WATTAGES

Choose the fully modular SFX PSU in black or white, with 850W or 750W options to perfectly match your build.



COMPACT SIZE, BIG PERFORMANCE

Measuring 125 × 100 × 63.5 mm, this compact PSU saves valuable space inside the builds without compromising on power delivery.



80 PLUS GOLD CERTIFICATE

With 80 PLUS Gold certification, the SP V2 Gold delivers over 90% efficiency at 50% system load under 115V AC input conditions, ensuring high energy efficiency with stable power delivery and minimal energy loss.



ATX 3.1 READY WITH 12V-2×6 CONNECTOR

The SP V2 Gold features a next-gen 12V-2×6 power connector compliant with the latest ATX 3.1 specification, providing direct support for PCIe 5.0 graphics cards and addressing the growing power demands of modern systems.



LIAN LI CUSTOM 12V-2×6 POWER CABLE

LIAN LI's in-house developed 12V-2×6 power cable features a custom-molded design combined with alloy copper soldered terminals to deliver superior stability and efficient power delivery. Built to meet the demanding needs of high-end graphics cards, this cable ensures safer, more durable connections for your cutting-edge system.



Each cable is engineered for ease of use, with dual-color connector housings for intuitive installation, reinforced soldering for improved reliability, and a 20.5mm connector width optimized to prevent interference during GPU mounting.



FDB FAN FOR QUIET COOLING

The SP V2 Gold utilizes a 92mm FDB fan to deliver efficient cooling with low noise. Even under sustained high workloads, it maintains stable performance while ensuring silent operation.



JAPANESE ELECTROLYTIC CAPACITORS

Premium Japanese electrolytic capacitors provide great durability and long-term reliability, as well as offer the highest stability.



REFINED DESIGN WITH FULLY MODULAR CABLES

The SP V2 Gold features a fully modular cable system with all necessary braided cables included out of the box, reducing clutter and enhancing visual appeal.



ENHANCED DURABILITY WITH EMBOSSED CABLE DESIGN

The embossed cable design enhances both durability and flexibility, ensuring long-lasting performance even under frequent use. Its unique textured surface helps reduce tangling and knotting, delivering a smoother installation experience and cleaner cable management.



SUFFICIENT PROTECTION

Features OCP (Over Current Protection), OVP (Over Voltage Protection), SCP (Short Circuit Protection), OPP (Over Power Protection), UVP (Under Voltage Protection), OTP (Over Temperature Protection) and inrush current limiter that make the PSU operating in stable condition.


  • Compact 125 × 100 × 63.5 mm SFX size for space-limited builds

  • 80 PLUS Gold certified with 90%+ efficiency at 50% load (115V)

  • ATX 3.1 & PCIe 5.0 ready with native 12V-2×6 GPU support

  • Exclusive 12V-2×6 cable design prevents GPU clearance issues

  • 92 mm FDB fan with ZERO RPM mode for silent operation

  • Fully modular design with anti-tangle embossed cables

  • Offering comprehensive protection mechanisms, including OCP, OVP, SCP, OPP, UVP, OTP



AC įėjimo dažnis 50/60 Hz
AC įėjimo įtampa 100 - 240 V
ATX versija 3.1
Aukštis 63.5 mm
Aušinimo padengimo tipas FDB
Bendroji galia 750 W
Bruto svoris 1.87 kg
CPU maitinimo laido ilgis 600 mm
Darbo temperatūros diapazonas (TT) 0 - 40 °C
Didžiausia išėjimo įtampa (+12 V) 62 A
Didžiausia išėjimo įtampa (+12 VSB) 3 A
Didžiausia išėjimo įtampa (+3,3 V) 20 A
Didžiausia išėjimo įtampa (+5 V) 20 A
Didžiausia išėjimo įtampa (-12 V) 0.3 A
Efektyvumas 90 %
EPS maitinimo jungtis (8-kaisčiai) Taip
Galios koeficiento pataisos (PFC) tipas Aktyvus
Garso lygis 32.5 dB
Ilgis 100 mm
Kompleksinė galia (+12 V) 744 W
Kompleksinė galia (+3,3 V) 100 W
Kompleksinė galia (+5 VSB) 15 W
Kompleksinė galia (+5V) 100 W
Kompleksinė galia (-12 V) 3.6 W
Maitinimo apsaugos ypatybės Apsauga nuo per didelės įtampos/Darbas be apkrovos/Minimaliosios įtampos apsauga/Per žema temperatūra/Surge & inrush protection (SIP)/Trumpasis jungimas/Viršijus galią/Viršijus nuolatinę srovę
Maitinimo bloko (PSU) formos koeficientas SFX
Model name SP750
Motininės plokštės maitinimo jungtis 20+4 pin ATX
Motininės plokštės maitinimo kabelio ilgis 350 mm
Neto svoris 1.7 kg
Paskirtis PC
PCI Express maitinimo jungtis (8 kaisčiai) 1
PCI "Express" galia kabelio ilgis 400 mm
PCI "Express" maitinimo jungtys (6 + 2 kontaktai) 2
Perdavimo laidu tipas Visiškai modulinis
Periferinio ("Molex") maitinimo kabelio ilgis 350 mm
Periferinė (Molex) galios jungtis (4-pin) 1
Plotis 125 mm
Produkto spalva Juoda
SATA elektros jungčių skaičius 7
SATA maitinimo kabelio ilgis 350 mm
Sertifikatas 80 PLUS 80 PLUS Gold
Shipping Box Depth 58 cm
Shipping Box Height 27 cm
Shipping Box Weight 18.7 kg
Shipping Box Width 40 cm
Summary Lian Li SP V2 Gold. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 35 cm, SATA power cable length: 350 mm. Purpose: PC, Power supply unit (PSU) form factor: SFX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 9.2 cm, Number of fans: 1 fan(s). Width: 125 mm, Depth: 100 mm, Height: 63.5 mm
Unit Box Height 0.11
Unit Box Length 0.25
Unit Box Width 0.19
Unit Brutto Volume 0.006264 cubm
Vendor Homepage https://lian-li.com/product/sp-v2/
Ventiliatoriaus greitis 0 - 3000 RPM
Ventiliatoriaus skersmuo 92 mm
Ventiliatorių skaičius 1 ventiliatorius(iai / ių)
Vieneto aukštis 11 cm
Vieneto gylis 25 cm
Vieneto plotis 19 cm
Vienetų skaičius vienoje siuntimo dėžėje 10
Įvesties srovė 5 - 10 A
