Power Supply, GIGABYTE, GP-UD1000GM, ATX 3.1, 1000 Watts, Efficiency 80 PLUS GOLD, PFC Active, GP-UD1000GMPG5V2
Product reference: 2-4719331556112

Power Supply, GIGABYTE, GP-UD1000GM, ATX 3.1, 1000 Watts, Efficiency 80 PLUS GOLD, PFC Active, GP-UD1000GMPG5V2

Product reference: 2-4719331556112
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
125,09 €
Product in warehouse

Guarantee
36 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.

  • Intel ATX 3.1 and PCIe Gen 5.1 ready
  • 80 PLUS Gold certified
  • Fully modular design
  • Powerful single +12V rail
  • Compact size
  • 100% Japanese capacitors
  • 120mm smart hydraulic bearing (HYB) van
  • Optimized thermal solution
  • OVP/OPP/SCP/UVP/OCP/OTP protection

AC input frequency50/60 Hz
AC input voltage100 - 240V
ATX version3.1
Height86 mm
Cooling coating typeHUB
Cooling typeActive
Total power1000 W
Gross weight2.7 kg
CPU power connector (4 + 4 pins)Yes
CPU power cable length600 mm
Maximum output voltage (+12 V)83.3 A
Maximum output voltage (+12 VSB)3 A
Maximum output voltage (+3.3 V)25 A
Maximum output voltage (+5 V)25 A
Maximum output voltage (-12 V)0.3 A
Efficiency90 %
Number of EPS connections2
Floppy drive power connector1
Power factor0.9
Power Factor Correction (PFC) TypeActive
Warranty period10 years
Length140 mm
Complex power (+12 V)1000 W
Complex power (+3.3 V)125 W
Complex power (+5 VSB)15 W
Complex power (+5V)125 W
Complex power (-12 V)3.6 W
Shelf life16 ms
Power protection featuresOvervoltage protection/Overheating protection/Undervoltage protection/Short circuit/Over power/Over DC current
Power supply unit (PSU) form factorATX
Model nameGP-UD1000GM
Motherboard power connector20+4 pin ATX
Motherboard power cable length610 mm
Net weight2.5 kg
On/off buttonYes
Package weight2640 g
Package height211 mm
Package depth269 mm
Package width618 mm
Packaging type"Box"
PurposePC
PCI Express power cable length700 mm
PCI Express connectorYes
PCI Express power connectors (6 + 2 pins)4
Wired transmission typeFully modular
Peripheral (Molex) power cable length120/150/500 mm
Peripheral (Molex) power connector (4-pin)3
Width150 mm
Product colorBlack
Number of SATA electrical connectors8
SATA power cable length150/600 mm
80 PLUS certificate80 PLUS Gold
Shipping Box Depth62 cm
Shipping Box Height28 cm
Shipping Box Weight13.5 kg
Shipping Box Width22.5 cm
SummaryGIGABYTE UD1000GM PG5 V2 Power Supply Unit- PCIe Gen 5.1, 80 PLUS Gold, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, EU Plug. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 150,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm
Weight2480 g
Unit Box Height0.21
Unit Box Length0.12
Unit Box Width0.255
Unit Ugly Volume0.007812 cubm
Vendor Homepagehttps://www.gigabyte.com/Power-Supply/GP-UD1000GM-PG5-rev-20#kf
Fan diameter120 mm
Number of fans1 fan(s)
Mean time between failures (MTBF)100000 h
Unit height21 cm
Unit depth12 cm
Unit width25.5 cm
Number of units per shipping box5
Input current15 - 6.5 A
PCI Express power connectors (16-pin)1
