Power Supply - Chieftec Value APB-700B8 700 W 20+4 pin Silver
Product reference:
14-753263077820
Chieftec Value APB-700B8 - 700 W ATX power supply with 80 PLUS Silver efficiency class certification, ensuring reliable protection and quiet cooling.
Power Supply - Chieftec Value APB-700B8 700 W 20+4 pin Silver
Product reference:
14-753263077820
Chieftec Value APB-700B8 - 700 W ATX power supply with 80 PLUS Silver efficiency class certification, ensuring reliable protection and quiet cooling.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Chieftec Value APB-700B8
Chieftec Value APB-700B8 is a 700W ATX power supply unit with 80 PLUS Silver efficiency class certification. It integrates advanced protection mechanisms and a quiet 12 cm fan for effective cooling.
- 80 PLUS Silver efficiency class for energy saving
- Quiet 12 cm fan for active cooling
- Comprehensive protection functions: short circuit, overload, etc.
- Incompatible cables with flexibility
- Compact dimensions: 140 mm depth, 87 mm height, 150 mm width
Technical data | |
|---|---|
| Sustainable development compliance | Yes |
| Sustainable development certificates | CE |
Design | |
| Product color | Silver |
| Number of fans | 1 |
| Fan diameter | 12 cm |
| Cooling type | Active |
Power supply | |
| Connected power (+12V) | 648 W |
| Power protection functions | Underpower, Overheating, Short circuit, Overvoltage, Undervoltage, Overload |
| Maximum output current (+12V1) | 54 A |
| Power factor | 0.9 |
| Total power | 700W |
| AC input voltage | 200 - 240V |
| Connected power (+5V) | 130W |
| Maximum output current (+3.3V) | 22 A |
| Input current | 5 A |
| AC input frequency | 47 - 63 Hz |
| Power Factor Correction (PFC) Type | Active |
| Maximum output current (+5V) | 22 A |
Weight and dimensions | |
| Depth | 140mm |
| Weight | 1.42 kg |
| Height | 87 mm |
| Width | 150mm |
Operation | |
| Purpose | PC/Server |
| Power supply unit (PSU) shape | ATX |
| ATX version | 2.3 |
| 80 PLUS certificate | 80 PLUS |
Packaging details | |
| Package weight | 1.57 kg |
Ports and interfaces | |
| Cable type | Incompatible |
| Motherboard power cable length | 55 cm |
| Floppy drive connector | Yes |
| SATA power cable lengths | 150, 550mm |
| Number of peripheral (Molex) power connectors (4-pin) | 2 |
| PCI Express power cable length | 50cm |
| Motherboard power connector | 20+4 pin ATX |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| Height | 120mm |
| Length | 350mm |
| Weight | 1800g |
| Width | 270mm |
