Power Supply - Chieftec Smart GPS-700A8 700 W Black
Product reference:
14-4710713239579
Chieftec Smart GPS-700A8 - 700 W ATX 2.3 power supply for desktop computers with active PFC, active cooling and a 120 mm fan. Integrated 20+4-pin motherboard, 8-pin EPS, six SATA and two 6+2-pin PCIe connectors, and the cables are non-separable.
Power Supply - Chieftec Smart GPS-700A8 700 W Black
Product reference:
14-4710713239579
Chieftec Smart GPS-700A8 - 700 W ATX 2.3 power supply for desktop computers with active PFC, active cooling and a 120 mm fan. Integrated 20+4-pin motherboard, 8-pin EPS, six SATA and two 6+2-pin PCIe connectors, and the cables are non-separable.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Chieftec Smart GPS-700A8 700 W ATX power supply, black
Chieftec Smart GPS-700A8 - 700 W ATX 2.3 power supply for desktop computers with active PFC, active cooling and a 120 mm fan. It has non-modular cable connection, a 20+4-pin motherboard connector, an 8-pin EPS connector, six SATA connectors and two 6+2-pin PCIe connectors.
- 700 W ATX power supply for desktop computers
- Active PFC and active cooling with silent 120mm fan
- Integrated protection against overvoltage, undervoltage, overload and short circuit
- 20+4 pin ATX, 8 pin EPS, two 6+2 pin PCIe, six SATA and two Molex connectors
Product information | |
|---|---|
| Product type | Desktop computer power supply |
| Brand | Chieftec |
| Model | Smart GPS-700A8 |
| Form factor | PS/2 |
| ATX standard | ATX 2.3 |
| Purpose | Desktop computer systems |
Power specifications | |
| AC voltage | 230V |
| Performance | 80% |
| Power factor | 0.9 |
| +12 V output current | 54 A |
| +5V output current | 22 A |
| +3.3V output current | 22 A |
| +5VSB output current | 2.5A |
| Total power of +5VSB | 12.5W |
| −12 V output current | 0.3A |
| Total −12 V power | 3.6W |
| 80 PLUS certificate | None |
Cooling and construction | |
| Cooling system | Active cooling |
| Number of fans | 1 |
| Fan diameter | 120mm |
| Body color | Black |
| Dimensions | 150 × 87 × 140 mm (width × height × depth) |
| Weight | 1.62 kg |
Connectors | |
| Cables | Non-modular |
| Floppy drive connector | 1 |
Safety and security | |
| Security features | Protection against overvoltage, undervoltage, overload and short circuit |
| Safety warning | Use only as an internal power supply with compatible desktop computers. Disconnect the power supply from the electrical outlet before installation or maintenance. Do not open or modify the device. |
| Height | 235 mm |
| Length | 120mm |
| Weight | 1746 g |
| Width | 170mm |
