Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS, PFC Active, APB-700B8
Product reference:
2-753263077820
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS, PFC Active, APB-700B8
Product reference:
2-753263077820
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
The new VALUE SERIES offers both quality and 80 PLUS® 230V EU efficiency at a highly competitive pricing. Equipped with a vast amount of required connectors, long native cables and a silent running fan with installed thermal board, the PSU runs quietly on full load and provides REAL POWER, thereby providing all security features. Certified by CE, CB, EAC, TÜV and amongst many others, it's the VALUE choice!
| 80 PLUS certification | 80 PLUS |
| AC input frequency | 47 - 63 Hz |
| AC input voltage | 200 - 240 V |
| ATX version | 2.3 |
| Cabling type | Non-Modular |
| Certification | CE, CB, EAC, TÜV |
| Combined power (+12V) | 648 W |
| Combined power (+3.3V) | 130 W |
| Combined power (+5V) | 130 W |
| Compliance certificates | CE |
| Cooling type | Active |
| CPU power cable length | 500 mm |
| CPU power connector (4+4 pin) | Yes |
| Depth | 140 mm |
| EPS power connector (4+4 pin) | Yes |
| Fan diameter | 120 mm |
| Floppy disk drive connector | Yes |
| Floppy drive power connector | 1 |
| Harmonized System (HS) code | 84733020 |
| Height | 87 mm |
| Input current | 5 A |
| Max output current (+12V1) | 54 A |
| Max output current (+3.3V) | 22 A |
| Max output current (+5V) | 22 A |
| Motherboard power cable length | 550 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 4 |
| Package weight | 1570 g |
| PCI Express power cable length | 500 mm |
| PCI Express power connectors (6+2 pin) | 2 |
| Peripheral (Molex) power cable length | 150/500 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over voltage/Overheating/Overload/Short circuit/Under power/Under voltage |
| Power supply unit (PSU) form factor | ATX |
| Product colour | Silver |
| Product Net Weight | 1.42 kg |
| Purpose | PC/Server |
| SATA power cable length | 150/550 mm |
| Shipping Box Depth | 49 cm |
| Shipping Box Height | 21 cm |
| Shipping Box Weight | 15.5200004577637 kg |
| Shipping Box Width | 45.5 cm |
| Summary | Chieftec Value APB-700B8. Total power: 700 W, AC input voltage: 200 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 150,550 mm. Purpose: PC/Server, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Silver, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: CE, Certification: CE, CB, EAC, TÜV |
| Sustainability compliance | Yes |
| Total power | 700 W |
| Unit Box Height | 0.09 |
| Unit Box Length | 0.22 |
| Unit Box Width | 0.155 |
| Unit Calculated Volume | 0.004682 cubm |
| Unit Calculated Weight | 1.55 kg |
| Units per Shipping Box | 10 |
| Vendor Homepage | https://www.chieftec.eu/products-detail/181/VALUE_SERIES/527/APB-700B8 |
| Weight | 1420 g |
| Width | 150 mm |
