Power Supply, CHIEFTEC, BDF-650C, PS / 2, PC, 115 - 230 V, 650 W, BDF-650C
Product reference: 2-4710713231283
Power Supply, CHIEFTEC, 650 Watts, Efficiency 80 PLUS BRONZE, PFC Active, BDF-650C
Power Supply, CHIEFTEC, 650 Watts, Efficiency 80 PLUS BRONZE, PFC Active, BDF-650C
Power Supply, CHIEFTEC, 650 Watts, Efficiency 80 PLUS BRONZE, PFC Active, BDF-650C
Power Supply, CHIEFTEC, 650 Watts, Efficiency 80 PLUS BRONZE, PFC Active, BDF-650C
Power Supply, CHIEFTEC, 650 Watts, Efficiency 80 PLUS BRONZE, PFC Active, BDF-650C
Power Supply, CHIEFTEC, 650 Watts, Efficiency 80 PLUS BRONZE, PFC Active, BDF-650C

Power Supply, CHIEFTEC, BDF-650C, PS / 2, PC, 115 - 230 V, 650 W, BDF-650C

Product reference: 2-4710713231283
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
80,17 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
3 - 5
business days

Your message has been successfully sent!
Fill in the required fields*

Блок живлення ATX 2.3 Chieftec PROTON 650W 80 PLUS Bronze Black (BDF-650C)



With the PROTON Series, CHIEFTEC advances into the new-age DC to DC power supply technology. The series allows for energy conservation, as well as a much higher efficiency and power stability, which in turn ensures a higher longevity of installed components. The efficiency of the PROTON Series is certified at 80 PLUS BRONZE thereby fulfilling all ENERGY STAR 5,0 and higher requirements as stipulated by the EU.


80 PLUS certification 80 PLUS Bronze
AC input frequency 50 - 60 Hz
AC input voltage 115 - 230 V
ATX version 2.3
Cabling type Fully-Modular
Combined power (+3.3V) 120 W
Combined power (+5V) 120 W
Cooling type Active
CPU power connector (4+4 pin) Yes
Depth 140 mm
Efficiency 85 %
Fan diameter 140 mm
Fan location Top
Floppy disk drive connector Yes
Harmonized System (HS) code 84733020
Height 87 mm
Manual Yes
Max output current (+12V) 54.2 A
Max output current (+3.3V) 22 A
Max output current (+5V) 22 A
Max output current (+5Vsb) 2.5 A
Max output current (-12V) 0.3 A
Model name BDF-650C
Motherboard power connector 20+4 pin ATX
Number of fans 1 fan(s)
Number of SATA power connectors 6
On/off switch Yes
Package type Box
PCI Express power connectors (6+2 pin) 4
Peripheral (Molex) power cable length 150/450 mm
Peripheral (Molex) power connectors (4-pin) 3
Power factor 0.9
Power Factor Correction (PFC) type Active
Power protection features Over current/Over voltage/Overheating/Overload/Short circuit/Under voltage
Power supply unit (PSU) form factor PS/2
Product colour Black
Product Net Weight 2.5 kg
Purpose PC
SATA power cable length 150/450 mm
Shipping Box Depth 51 cm
Shipping Box Height 18 cm
Shipping Box Weight 15 kg
Shipping Box Width 48 cm
Status 20+4 PIN ATX 1
8 PIN EPS (4+4) 1
8 PIN PCIe (6+2) 4
SATA 6
MOLEX/FLOPPY 3/1
Summary Chieftec BDF-650C. Total power: 650 W, AC input voltage: 115 - 230 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 14 cm. Width: 150 mm, Depth: 140 mm, Height: 87 mm
Total power 650 W
Unit Box Height 0.21
Unit Box Length 0.33
Unit Box Width 0.1
Unit Calculated Volume 0.007344 cubm
Unit Calculated Weight 2.5 kg
Unit Depth 33 cm
Unit Height 21 cm
Unit Width 10 cm
Units per Shipping Box 6
Vendor Homepage https://www.chieftec.eu/products-detail/160/PROTON_SERIES/165/BDF-650C
Warranty card Yes
Width 150 mm
