MSI MAG A1000GL PCIE5 II power supply unit 1000 W 24-pin ATX ATX Black
Product reference:
6-306-7ZP9D11-CE0
MSI MAG A1000GL PCIE5 II power supply unit 1000 W 24-pin ATX ATX Black
MSI MAG A1000GL PCIE5 II power supply unit 1000 W 24-pin ATX ATX Black
Product reference:
6-306-7ZP9D11-CE0
MSI MAG A1000GL PCIE5 II power supply unit 1000 W 24-pin ATX ATX Black
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
84 month
Delivery from Europe in
5 - 9
business days
| 80 PLUS certification | 80 PLUS Gold |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| ATX version | 3.1 |
| Bearing technology | FDB |
| Cabling type | Fully-Modular |
| Combined power (+12V) | 999.6 W |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 3.6 W |
| Cooling type | Active |
| Depth | 150 mm |
| Efficiency | 90% |
| EPS power connector (4+4 pin) | Yes |
| EPS power connector (8-pin) | No |
| Fan diameter | 13.5 cm |
| Fan speed | 500 - 1800 RPM |
| Height | 86 mm |
| Illumination | No |
| Max output current (+12V) | 83.3 A |
| Max output current (+3.3V) | 22 A |
| Max output current (+5V) | 22 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Motherboard power cable length | 60 cm |
| Motherboard power connector | 24-pin ATX |
| Number of +12V rail(s) | 1 |
| Number of fans | 1 fan(s) |
| Number of SATA power connectors | 12 |
| On/off switch | Yes |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power cable length | 450 mm, 500 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over current, Overheating, Over power, Over voltage, Short circuit, Under voltage |
| Power supply unit (PSU) form factor | ATX |
| Product colour | Black |
| Purpose | PC |
| SATA power cable length | 150, 500 |
| Total power | 1000 W |
| Weight | 169 g |
| Width | 150 mm |
