DeepCool PF600X power supply unit

Product reference: 6-R-PF600X-HD0B-JGEU

DeepCool PF600X power supply unit

Product reference: 6-R-PF600X-HD0B-JGEU

DeepCool PF600X power supply unit

You have 3 products in compare list, please remove someone and try again

Add to compare

4947 €

Product in warehouse

Guarantee
36 month

Delivery from Europe in
9 - 14
business days

Sustainability certificates	Triman, WEEE, China RoHS
Sustainability compliance	Yes
Number of fans	1 fan(s)
Fan diameter	12 cm
Cooling type	Active
Product colour	Black
Combined power (+3.3V)	100 W
Total power	600 W
Max output current (-12V)	0.3 A
Max output current (+12V)	50 A
Power Factor Correction (PFC) type	Active
Max output current (+5Vsb)	3 A
Power Good signal delay range	100 - 150 ms
Combined power (-12V)	3.6 W
Power protection features	OPP, SCP, UVP, OCP, OVP, SIP, NLO, OTP
Max output current (+3.3V)	16 A
Combined power (+12V)	600 W
Efficiency	88%
Max output current (+5V)	16 A
Combined power (+5V)	100 W
Combined power (+5Vsb)	15 W
Hold time	16 ms
Input current	5 A
AC input voltage	200 - 240 V
AC input frequency	50/60 Hz
Operating temperature (T-T)	0 - 40 °C
Height	86 mm
Depth	140 mm
Width	150 mm
ATX version	2.52
Bearing technology	HYB
Purpose	PC
80 PLUS certification	80 PLUS Bronze
Mean time between failures (MTBF)	40000 h
Power supply unit (PSU) form factor	ATX
Cables included	AC
Compliance certificates	CCC, RCM, KC, CE
Motherboard power connector	24-pin ATX
PCI Express power connectors (6+2 pin)	2
Number of SATA power connectors	8
Motherboard power cable length	55 cm
SATA power cable length	600 mm, 450 mm, 900, 750
CPU power connector (4+4 pin)	Yes
