Chieftec Task TPS-500S power supply unit 500 W 24-pin ATX ATX Black
Product reference:
6-TPS-500S
Chieftec Task TPS-500S power supply unit 500 W 24-pin ATX ATX Black
Chieftec Task TPS-500S power supply unit 500 W 24-pin ATX ATX Black
Product reference:
6-TPS-500S
Chieftec Task TPS-500S power supply unit 500 W 24-pin ATX ATX Black
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
9 - 13
business days
| Sustainability certificates | RoHS |
| Fan location | Side |
| Product colour | Black |
| Fan diameter | 12 cm |
| On/off switch | Yes |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| AC input voltage | 115 - 230 V |
| Power protection features | Over power, Overload, Short circuit, Over voltage |
| Total power | 500 W |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 110 W |
| AC input frequency | 47 - 63 Hz |
| Max output current (+3.3V) | 18 A |
| Max output current (+5V) | 17 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (+12V1) | 38 A |
| Combined power (+5V) | 110 W |
| Efficiency | 85% |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
| Certification | ErP, RoHS, CE, CB, EAC, TÜV |
| 80 PLUS certification | 80 PLUS Bronze |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 2.3 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| EPS power connector (4+4 pin) | Yes |
| Number of SATA power connectors | 5 |
| PCI Express power connectors (6+2 pin) | 2 |
| Motherboard power connector | 24-pin ATX |
| Harmonized System (HS) code | 84733020 |
