ATX 2.3 power supply Chieftec A-80 750W 80 PLUS Black (CTG-750C)
this popular PSU series is now extended by new models featuring cable management. With many awards granted, these PSUs are perfectly suited for cost aware users, who pay attention to both good price and high efficiency.
| AC input frequency | 50 Hz |
| AC input voltage | 230V |
| Certificates of conformity | RoHS |
| ATX version | 2.3 |
| Height | 87 mm |
| Cooling type | Active |
| Total power | 750 W |
| Gross weight | 2.45 kg |
| CPU power connectors (8 pins) | 1 |
| CPU P4 connector (4 pins) | 1 |
| Harmonized System (HS) code | 84733020 |
| Maximum output voltage (+12 V1) | 35 A |
| Maximum output voltage (+12 V2) | 35 A |
| Maximum output voltage (+12 VSB) | 3 A |
| Maximum output voltage (+3.3 V) | 22 A |
| Maximum output voltage (+5 V) | 22 A |
| Maximum output voltage (-12 V) | 0.3 A |
| Efficiency | 85 % |
| EPS power connector (8-pin) | Yes |
| Floppy drive power connector | 2 |
| Power factor | 0.9 |
| Power Factor Correction (PFC) Type | Active |
| Length | 140 mm |
| Complex power (+12 V) | 648 W |
| Complex power (+3.3 V) | 130 W |
| Complex power (+5 VSB) | 15 W |
| Complex power (+5V) | 130 W |
| Complex power (-12 V) | 3.6 W |
| Power protection features | Overvoltage protection/Overheating protection/Overload protection/Undervoltage protection/Short circuit/Exceeding DC current |
| Power supply unit (PSU) form factor | ATX |
| Motherboard power connector | 24-pin ATX |
| Net weight | 1.8 kg |
| Packaging type | "Box" |
| Purpose | PC |
| PCI Express power connectors (6 + 2 pins) | 2 |
| Wired transmission type | Semi-modular |
| Peripheral (Molex) power cable length | 150/450 mm |
| Peripheral (Molex) power connector (4-pin) | 4 |
| Width | 150 mm |
| Product color | Black |
| Number of SATA electrical connectors | 6 |
| SATA power cable length | 150/450 mm |
| 80 PLUS certificate | 80 PLUS |
| Certification | CE, CB, FCC |
| Shipping Box Depth | 52 cm |
| Shipping Box Height | 21 cm |
| Shipping Box Weight | 19.6 kg |
| Shipping Box Width | 43 cm |
| Summary | Chieftec CTG-750C. Total power: 750 W, AC input voltage: 230 V, AC input frequency: 50 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Semi-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, Certification: CE, CB, FCC |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.25 |
| Unit Box Width | 0.19 |
| Unit Ugly Volume | 0.005869 cubm |
| Vendor Homepage | https://www.chieftec.eu/products-detail/107/A-80_SERIES/130/CTG-750C |
| Fan diameter | 120 mm |
| Fan location | Top |
| Number of fans | 1 fan(s) |
| Mean time between failures (MTBF) | 100000 h |
| Unit height | 10 cm |
| Unit depth | 25 cm |
| Unit width | 19 cm |
| Number of units per shipping box | 8 |
| Input current | 6 A |
