Equip 650370 signage display mount

Equip 32"-65" Ceiling Mount Dual Screen TV Bracket. Maximum weight capacity: 80 kg, Minimum screen size: 81.3 cm (32"), Maximum screen size: 165.1 cm (65"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 600 x 400 mm. Tilt angle range: -5 - 15°. Product colour: Black

The industrial-grade double TV ceiling mount from equip is the perfect choice for signage applications. The adjustable tilt device allows installation with precise and even screen tilt of the mounted screens for optimal screen visibility. The ideal choice to advertise to the public

Mounting

Maximum weight capacity: 80 kg
Minimum screen size: 81.3 cm (32")
Number of displays supported: 2
Maximum screen size: 165.1 cm (65")
Mounting type: Ceiling
Minimum VESA mount: 100 x 100 mm
Maximum VESA mount: 600 x 400 mm

Ergonomics

Feature: Height adjustment
Tilt angle range: -5 - 15°
Angle of rotation: 30°
Feature: Cable management

Design

Product colour: Black
Housing material: Steel
Certification: CE, RoHS

Weight & dimensions

Width: 1500 mm
Depth: 300 mm
Height: 600 mm
Weight: 16 kg

Packaging data

Package width: 342 mm
Package depth: 135 mm
Package height: 900 mm
Package weight: 17 kg

Packaging content

Feature: Manual
Feature: Mounting kit

Other features

Country of origin: China

Logistics data

Harmonized System (HS) code: 85299097
Master (outer) case width: 135 mm
Master (outer) case length: 342 mm
Master (outer) case height: 900 mm
Master (outer) case gross weight: 17 kg
Products per master (outer) case: 1 pc(s)
