Epson PLQ-50M dot matrix printer

Epson PLQ-50M. Maximum print speed: 630 cps, Maximum resolution: 180 x 360 DPI, Maximum print speed (draft): 420 cps. Product colour: Black, White, Buffer size: 128 KB, Page description languages: Epson ESC/P2, PPDS. Standard interfaces: RS-232, USB 2.0. Print head: 24-pin, Print head life: 600 million characters, Mean time between failures (MTBF): 35000 h. AC input voltage: 100-240 V, AC input frequency: 50 - 60 Hz
24-pin dot matrix printer
Fast and reliable 24-pin dot matrix printer series, with the capability to handle passbooks and an LCD screen for better usability.
Ideal for the banking sector and post offices, the PLQ-50 models are a dot matrix printer series that is ultra-reliable and has the capability to handle passbooks. It is fast, economical to run, and it features an LCD screen for user convenience.
When upgrading existing passbook printers, the premium performance of the PLQ-50 series makes it the ideal choice. With an improved mean time between failures of 35,000 hours and reliable dot matrix technology, you can depend on these printers to deliver high-quality output with minimal intervention.
Equally, when time is tight, the PLQ-50 series delivers fast printing of up to 560 characters per second (High-Speed-Draft, 10cpi), utilising 24-pins and 94 columns. Additionally, up to 6 copies can be produced simultaneously with the original.
The printer's performance is matched by its cost-effectiveness. The ribbon is compatible across all of the Epson Passbook range and represents a budget friendly printing solution.
An LCD screen also provides valuable user convenience.

Printing

Maximum resolution: 180 x 360 DPI
Maximum printing width (columns): 94
Maximum print speed: 630 cps
Maximum print speed (draft): 420 cps
Maximum print speed (LQ): 140 cps
Maximum print speed (NLQ): 210 cps
Character pitch: 10 cpi
Maximum number of copies: 6 copies
Built-in barcodes: CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, UPC-A, UPC-E
Character sets: PCAPTEC, PC437, PC708, PC720, PC850, PC858, PC864, PCAR864, ISO 8859-15, Roman 8, Italic
Number of characters: 14

Features

Product colour: Black, White
Buffer size: 128 KB
Page description languages: Epson ESC/P2, PPDS
Country of origin: Indonesia

Ports interfaces

Standard interfaces: RS-232, USB 2.0

Endurance

Print head: 24-pin
Print head life: 600 million characters
Mean time between failures (MTBF): 35000 h

Power

AC input voltage: 100-240 V
AC input frequency: 50 - 60 Hz

Operational conditions

Operating temperature (T-T): 5 - 38 °C
Storage temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 10 - 80%

Weight dimensions

Width: 384 mm
Depth: 280 mm
Height: 203 mm

Packaging data

Quantity per pack: 1 pc(s)
Package width: 365 mm
Package depth: 445 mm
Package height: 255 mm
Package weight: 10.4 kg

Other features

Print technology: Dot matrix
Needles: 24 (2 x 12)

Logistics data

Products per pallet (UK): 48 pc(s)
Pallet weight (UK): 0 g
Harmonized System (HS) code: 84433210
