Epson LQ-590IIN dot matrix printer

Epson LQ-590IIN. Maximum print speed: 550 cps, Character pitch: 10 cpi, Maximum number of copies: 6 copies. Paper tray media types: Envelopes, Labels, Roll, Continuous paper thickness range: 0.065 - 0.49 mm, Label thickness range: 0.16 - 0.19 mm. Product colour: Black, Buffer size: 128 KB, Sound pressure level (printing): 55 dB. Standard interfaces: Ethernet, Parallel, USB 2.0. Print head: 24-pin, Print head life: 400 million characters, Mean time between failures (MTBF): 25000 h
The LQ-590IIN is a high-volume dot matrix printer designed for fast and reliable printing. Upgrade your existing dot matrix printers to our latest model, which is now Energy Star compliant, and delivers built-in network capability with an incredibly low TCO.
Fast print speed
The LQ-590IIN offers an improved USD (ultra speed draft) speed of 550 characters per second at 10 characters per inch, making a real difference to high-volume print runs such as stock reports and large batches of invoices or freight documents.
Increased reliability
Epson's dot matrix technology is already mature and very reliable. Building on this, the new printer improves the mean time between failure by 25% to 25,000 power-on hours, ideal for challenging conditions or where regular maintenance is not practical.
Same consumables
This printer uses the same ribbons as existing models, so you can upgrade your hardware and continue to use your current ribbon supplies.
Network capability
This is a network model which supports both serial and Ethernet connections for enhanced connectivity.

Printing

Maximum printing width (columns): 80
Colour: No
Maximum print speed: 550 cps
Character pitch: 10 cpi
Maximum number of copies: 6 copies
Built-in barcodes: Code 128 (A/B/C), Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E
Character sets: PC437, PC708, PC720, PC850, PC858, PC864, PCAR864, ISO 8859-15, Roman 8, Italic
Print speed: Ultra Speed-Draft: 10 cpi: 550 chars/s

Paper handling

Paper tray media types: Envelopes, Labels, Roll
Continuous paper thickness range: 0.065 - 0.49 mm
Label thickness range: 0.16 - 0.19 mm
Multi-part paper thickness range: 0.12 - 0.46 mm
Single sheet thickness range: 0.065 - 0.14 mm

Features

Product colour: Black
Buffer size: 128 KB
Sound pressure level (printing): 55 dB
Country of origin: Indonesia

Ports interfaces

Standard interfaces: Ethernet, Parallel, USB 2.0

Endurance

Print head: 24-pin
Print head life: 400 million characters
Mean time between failures (MTBF): 25000 h

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 10 - 80%

System requirements

Windows operating systems supported: Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Server operating systems supported: Windows Server 2008 R2, Windows Server 2016

Weight dimensions

Width: 437 mm
Depth: 375 mm
Height: 177 mm
Weight: 7.2 kg

Packaging data

Quantity per pack: 1 pc(s)
Package width: 40 mm
Package depth: 340 mm
Package height: 80 mm
Package weight: 9.28 kg

Other features

Standard media sizes: Sheet Paper (single- and multi-layer), Continuous Paper (single- and multi-layer), Labels (single- and multi-layer), Roll Paper, Envelopes, Cardboard
Connectivity technology: Wired
Print technology: Dot matrix
Needles: 24 Needles
Compatible operating systems: Windows 10, Windows 7, Windows 8, Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2008 R2, Windows Server 2016, Windows Vista, Windows XP

Technical details

Sustainability certificates: ENERGY STAR

Logistics data

Products per pallet: 14 pc(s)
Pallet gross weight: 0 g
Pallet gross length: 120 cm
Pallet gross width: 80 cm
Pallet gross height: 7.43 m
Products per pallet layer: 2 pc(s)
Products per pallet layer (UK): 4 pc(s)
Products per pallet (UK): 28 pc(s)
Pallet weight (UK): 0 g
Pallet length (UK): 120 cm
Pallet width (UK): 100 cm
Pallet height (UK): 7.43 m
Harmonized System (HS) code: 84433210
