Brother ADS-4100 scanner

Brother ADS-4100. Maximum scan size: 215.9 x 355.6 mm, Optical scanning resolution: 600 x 600 DPI, Enhanced scan resolution: 1200 x 1200 DPI. Scanner type: ADF scanner, Product colour: Black, White, Control type: Buttons. Sensor type: Dual CIS, Scan to: Image, PC, USB, Scan drivers: ICA, SANE, WIA. Auto document feeder (ADF) input capacity: 60 sheets. Maximum ISO A-series paper size: A4, Scanning media types supported: Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper, Card thickness (max): 1.1 mm
Simple and intuitive. This highly versatile scanner is ideal for businesses that need to digitise a wide range of media, from paper to plastic cards, whether at home or in the office. Advanced image processing Driver compatibility with TWAIN (Win and macOS), WIA, ICA, Linux SANE

Scanning

Maximum scan size: 215.9 x 355.6 mm
Optical scanning resolution: 600 x 600 DPI
Enhanced scan resolution: 1200 x 1200 DPI
Colour scanning: Yes
Duplex scanning: Yes
Greyscale levels: 256
ADF scan speed (b/w, A4): 35 ppm
ADF scan speed (colour, A4): 35 ppm
Duplex ADF scan speed (b/w, A4): 70 ipm
Duplex ADF scan speed (colour, A4): 70 ipm

Design

Scanner type: ADF scanner
Product colour: Black, White
Control type: Buttons
Built-in display: No

Performance

Sensor type: Dual CIS
Scan to: Image, PC, USB
Scan drivers: ICA, SANE, WIA
Scanning noise level: 59 dB

Input capacity

Auto document feeder (ADF) input capacity: 60 sheets

Paper handling

Scanning media types supported: Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size: A4
Card thickness (max): 1.1 mm
Auto Document Feeder (ADF) media weight: 40 - 200 g/m²
Maximum scan width: 21.6 cm
Maximum scan length: 35.5 cm

Ports interfaces

USB port: Yes
USB version: 2.0

Power

Power supply type: AC
Power consumption (typical): 23 W
Power consumption (standby): 5.4 W
Power consumption (off): 0.1 W
Power consumption (sleep): 1.4 W

Weight dimensions

Width: 243 mm
Depth: 320 mm
Height: 391 mm
Weight: 3.02 kg

Packaging data

Package width: 391 mm
Package depth: 320 mm
Package height: 243 mm
Package weight: 3.7 kg

Packaging content

Cables included: AC, USB

System requirements

Windows operating systems supported: Yes
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Server operating systems supported: Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%

Other features

Spare part retention: 5 year(s)

Technical details

Pallet type: 800 x 1200 mm

Logistics data

Products per pallet: 50 pc(s)
Country of origin: China
Master (outer) cases per pallet: 50 pc(s)
Layers per pallet: 5 pc(s)
Pallet gross weight: 202 kg
Pallet gross height: 17.7 cm
Master (outer) cases per pallet layer: 10 pc(s)
Harmonized System (HS) code: 84716070
