Bambu Lab H2S AMS Combo

Bambu Lab H2S AMS Combo - Technical data

Product name: Bambu Lab H2S AMS Combo

Printer type: High-speed CoreXY 3D printer with automatic material system (AMS)

Printer specifications

• Printer volume: 256 × 256 × 256mm


• Printing technology: Fusion filament fabrication (FFF)


• Maximum print speed: 500 mm/s


• Maximum acceleration: 20,000 mm/s²


• Spray tip temperature: By 300°C


• Hot head type: Bambu Lab H2S high flow hot head


• Spray nozzle diameter: 0.4 mm (standard), optional 0.2 / 0.6 / 0.8 mm


• Layer height: 0.1-0.4mm


• Extruder type: Direct drive


• Thread diameter: 1.75mm


• Supported materials: PLA, PETG, TPU, ABS, ASA, PC, PA, PA-CF, PET-CF, etc.


• Bedside temperature: By 100°C


• Building board: Textured PEI / Smooth PEI (depending on configuration)


• Cooling system: Dual fan part cooling + hot head cooling fan


• Printing accuracy: ±0.1mm


• Frame material: Metal CoreXY structure


• Noise level: < 48 dB (average)

AMS (Automatic Material System) specifications

• Material slots: 4 independent thread compartments


• Supported thread types: PLA, PETG, TPU, ABS, ASA, PC, PA, CF composites


• Humidity control: Active sealed storage with dryer


• Automatic thread switching: Yes


• Thread detection: RFID tag support (Bambu Lab rolls)


• Thread end sensor: Yes


• AMS communication: Integrated with the printer via the Bambu Lab system


• AMS power source: Powered directly from the printer

Connectivity and software

• Wireless connection: Wi-Fi 2.4 GHz


• Wired connection: LAN (depending on model)


• Cloud support: Bambu Studio, Bambu Handy


• File formats: 3MF, STL, OBJ, STEP


• Slicer compatibility: Bambu Studio (recommended), OrcaSlicer

Security and monitoring

• Camera: Built-in surveillance camera (depending on model)


• Automatic calibration:



  • Bedside ironing


  • Vibration compensation


  • Leakage calibration






• Security features:



  • Thermal runaway protection mechanism


  • Closed thread path


  • Power loss recovery


  • Thread jam detection





Physical specifications

• Printer dimensions: 386 × 389 × 457mm


• Weight: ~14 kg


• AMS dimensions: 366 × 210 × 150mm


• AMS weight: ~2.5 kg


• Power input: 100-240V AC, 50/60 Hz


• Power consumption: By 350W

Included in the package

• Bambu Lab H2S 3D printer


• AMS device (4‑lizdų)


• PEI building board


• 0.4 mm spray tip (pre-installed)


• Thread cutter


• Tool kit


• Power cord


• Quick Start Guide

```
