3D Scanner - Revopoint MetroX Pro 0.01 mm Accuracy, 7,000,000 Points/Sec, Black
Product reference:
14-6975577881755
The Revopoint MetroX Pro Standard 3D scanner uses multi-fiber laser and structured lighting technology to provide accuracy down to 0.01 mm and 0.02 mm. It supports handheld and tripod-mounted scanning modes, allowing it to capture objects from 10 × 10 × 10 mm to 1 × 1 × 1 m at speeds of up to 7,000,000 points per second.
3D Scanner - Revopoint MetroX Pro 0.01 mm Accuracy, 7,000,000 Points/Sec, Black
Product reference:
14-6975577881755
The Revopoint MetroX Pro Standard 3D scanner uses multi-fiber laser and structured lighting technology to provide accuracy down to 0.01 mm and 0.02 mm. It supports handheld and tripod-mounted scanning modes, allowing it to capture objects from 10 × 10 × 10 mm to 1 × 1 × 1 m at speeds of up to 7,000,000 points per second.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
Revopoint MetroX Pro Standard 3D Scanner
The Revopoint MetroX Pro Standard 3D scanner uses multi-line laser and structured light technology to achieve 0.01 mm accuracy and 0.02 mm precision. It supports handheld and tripod-mounted scanning modes, capturing objects from 10 × 10 × 10 mm to 1 × 1 × 1 m at speeds of up to 7,000,000 points per second.
- High scanning accuracy of 3D with an accuracy of up to 0.02 mm and a speed of 7,000,000 points per second.
- Versatile scanning modes for a variety of surfaces, including handheld and stationary options.
- Compact and lightweight design, allowing for easy transport and use in a variety of environments.
- Compatible with multiple file formats, ensuring seamless integration into 3D modeling and printing processes.
Features | |
|---|---|
| Product type | 3D Scanner |
| Brand | Revopoint |
| Model | MetroX Pro Standard |
Specifications | |
| Scan type | Hand-held or tripod-mounted |
| Technology | Multi-line laser scanning and full-field structured light |
| Single shot accuracy (max.) | 0.01mm |
| Single shot accuracy (max.) | 0.02mm |
| Scope accuracy | 0.02 mm + 0.04 mm × L (m), where L is the length of the object |
| Working distance | 200~400mm |
| Scanning area (closest distance) | 160 × 70 mm at 200 mm |
| Scanning area (farthest distance) | 320 × 215 mm at 400 mm |
| Field of view (vertical × horizontal) | 43 × 33° |
| Minimum scan volume | 10 × 10 × 10 mm |
| Maximum scan volume | 1 × 1 × 1m |
| Scanning speed (max.) | 2,000,000 points/s (multi-line laser) / 7,000,000 points/s (full field) |
| RGB camera resolution | 2 MP |
| Tracking methods | Feature, Marker, Global Marker |
| 3D light source | 30 blue cross lasers, 15 blue parallel lasers, 62 blue structured light lines |
| Processor | 4-core ARM, 2.0 GHz |
| Compatible operating systems | Windows 10/11 (64-bit), macOS 11.0 or later |
| Output file formats | PLY, OBJ, STL, ASC, 3MF, GLTF, FBX |
| Connector type | USB Type-C to Type-C |
| Power source | DC 12V, 3A |
| Scanner weight | 508 grams |
| Dimensions (Length × Width × Height) | 209 × 88 × 44mm |
| Height | 100mm |
| Length | 300mm |
| Weight | 700g |
| Width | 200mm |
