Wi-Fi, Bluetooth controlled smart relay Shelly Pro Dimmer 2PM
Product reference: 26-3800235268179
  • Type: Smart Dimmable Relay
  • Model: Shelly Pro Dimmer 2PM
  • Mounting: On DIN rail
  • Connection: LAN, Wi-Fi, Bluetooth
  • Voltage: 110-240VAC
  • Maximum power: 200 W
  • Control: Via Shelly Smart Control app or voice assistants (Alexa, Home Assistant)
Wi-Fi, Bluetooth controlled smart relay Shelly Pro Dimmer 2PM

Wi-Fi, Bluetooth controlled smart relay Shelly Pro Dimmer 2PM

Product reference: 26-3800235268179
  • Type: Smart Dimmable Relay
  • Model: Shelly Pro Dimmer 2PM
  • Mounting: On DIN rail
  • Connection: LAN, Wi-Fi, Bluetooth
  • Voltage: 110-240VAC
  • Maximum power: 200 W
  • Control: Via Shelly Smart Control app or voice assistants (Alexa, Home Assistant)
You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
69,88 €
Product in warehouse

Guarantee
24 month

Delivery from Lithuania in
2 - 4
business days

Your message has been successfully sent!
Fill in the required fields*
  • General characteristics
  • Size (Height × Width × Depth) 94x19x69mm / 3.70x0.75x2.71in
  • Weight 75g / 2.7oz
  • Maximum torque of screw terminals 0.4 Nm / 3.54 lbin
  • Wire cross-sectional area 0.5 to 2.5 mm² / 20 to 14 AWG (green connectors), 0.5 to 1.5 mm² / 20 to 16 AWG (blue connector)
  • Length of stripped wire insulation 6 to 7 mm / 0.24 to 0.28 in (green connectors), 5 to 6 mm / 0.20 to 0.24 in (blue connector)
  • Installation DIN rail
  • Housing material Plastic
  • Body color Lime
  • Ambient operating temperature -20 °C to 40 °C / -5 °F to 105 °F
  • Humidity 30% to 70% RH
  • Maximum height 2000 m / 6562 ft
  • Power source 110 - 240 V~ 50/60 Hz
  • Energy consumption < 2W
  • External protection 10 A, tripping characteristic B or C, 6 kA interrupting rating, energy limiting class 3
  • Dimming type Trailing edge
  • Max. output power 200 W per channel
  • Voltmeter (AC) Yes
  • Ammeter (AC) Yes
  • Power and energy meters Yes
  • Internal temperature sensor Yes
  • Wi-Fi protocol 802.11 b/g/n
  • Wi-Fi RF band 2401 - 2483 MHz
  • Wi-Fi Max RF power < 20 dBm
  • Wi-Fi range Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (depends on local conditions)
  • Bluetooth protocol 4.2
  • Bluetooth RF band 2400 - 2483.5 MHz
  • Bluetooth maximum RF power < 4 dBm
  • Bluetooth operating range Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (depends on local conditions)
  • Processor ESP32-D0WDQ6
  • Flash (memory) 8MB
  • Schedules/timetables 20
  • Webhooks (URL actions) 20 with 5 URLs per hook
  • Scripting Yes
  • MQTT Yes

Manufacturer codeSHELLYPRODIMMER2
ManufacturerShelly
Weight0 kg
