UPS, EATON, 5000 Watts, 5000 VA, Wave form type Sinewave, 9PX5KIRTNG2
Product reference:
2-3553340710551
UPS, EATON, 5000 Watts, 5000 VA, Wave form type Sinewave, 9PX5KIRTNG2
Product reference:
2-3553340710551
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 5
business days
Eaton 9PX Gen2 UPS Netpack, 5000 VA, 5000 W, Input: Hardwired, Outputs: (6) C13, (6) C39, Hardwired, Rack/tower, 3U, Gigabit Network card included, Rack-mounting kit included
| Summary | Eaton 9PX 5000i RT3U Netpack G2. UPS topology: Double-conversion (Online), Output power capacity: 5 kVA, Output power: 5000 W. AC outlet types: C13 coupler, Hardwire, C39 coupler. Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 5 Ah, Battery voltage: 12 V. Form factor: Rackmount/Tower, Product colour: Black, Silver, Rack capacity: 3U. Compliance certificates: CB, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD), RCM, REACH, RoHS, UKCA,..., Certification: IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 |
| Vendor Homepage | https://www.eaton.com/de/en-gb/skuPage.9PX5KIRTNG2.html |
| Unit Box Height | 0.31 |
| Unit Box Length | 0.59 |
| Unit Box Width | 0.96 |
| Efficiency | 96.7 % |
| Efficiency (ECO mode) | 99 % |
| Heat dissipation | 563 BTU/h |
| Input frequency | 40/70 Hz |
| Input operation voltage (max) | 276 V |
| Input operation voltage (min) | 100 V |
| Input power factor | 0.99 |
| Noise level | 40 dB |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Output frequency | 50/60 Hz |
| Output operation voltage (max) | 240 V |
| Output operation voltage (min) | 200 V |
| Output power | 5000 W |
| Output power capacity | 5 kVA |
| Power consumption (average operating) | 165 W |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| AC outlet types | C13 coupler/C39 coupler/Hardwire |
| Network card slot | Yes |
| RS-232 ports | 1 |
| USB port | Yes |
| Automatic battery test | Yes |
| Battery capacity | 5 Ah |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 12 V |
| Typical backup time at half load | 9.4 min |
| Cable length | 1.8 m |
| Display type | LCD |
| Form factor | Rackmount/Tower |
| LED indicators | Yes |
| Product colour | Black,Silver |
| Rack capacity | 3U |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Cables included | USB cable |
| Certification | IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 |
| Compliance certificates | CB/CE/cULus/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)/RCM/REACH/RoHS/UKCA/WEEE |
| Quick installation guide | Yes |
| Sustainability certificates | ENERGY STAR |
| Depth | 684 mm |
| Height | 130 mm |
| Weight | 43100 g |
| Width | 440 mm |
| Model | 9PX5KIRTNG2 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.1756 cubm |
| Unit Calculated Weight | 55 kg |
