Surge Protection Device - Surge Protection Relay with Reset Function, 1P+N, 63A, 230V
Product reference:
14-6942034339654
Surge protector for AC 230V circuits, with a maximum current of 63A. It features automatic circuit disconnection and reconnection, LED indicators and the possibility of mounting on a DIN rail.
Surge Protection Device - Surge Protection Relay with Reset Function, 1P+N, 63A, 230V
Product reference:
14-6942034339654
Surge protector for AC 230V circuits, with a maximum current of 63A. It features automatic circuit disconnection and reconnection, LED indicators and the possibility of mounting on a DIN rail.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
4 - 5
business days
Not available
Voltage Protection Relay with Reset Function, 1P+N, 63A, 230V
Self-resetting overload and undervoltage protection device for AC 230V circuits with a maximum current of 63A. Features: automatic circuit disconnection and reconnection, LED indicators and DIN rail mounting.
- Automatic overload and undervoltage protection for AC 230V circuits up to 63A.
- The self-recovery function ensures automatic power restoration when the voltage returns to normal.
- Compact design for easy DIN rail mounting, perfect for home distribution boxes.
- LED indicators for power and security status for quick visual feedback.
Features | |
|---|---|
| Product Type | Surge Protection Device |
| Model | Self-Resetting Overload and Underground Voltage Protection Device |
Specifications | |
| Nominal Voltage | AC 230V |
| Current | 63 A |
| Frequency | 50/60Hz |
| Overload Trip Value | AC 270V ±5V |
| Underground Voltage Trip Value | AC 170V ±5V |
| Overload Recovery Value | AC 255V ±5V |
| Underground Voltage Recovery Value | AC 185V ±5V |
| Reaction Time | <= 1s |
| Recovery Time | <= 60s |
| Pole | 1P+N |
| Power | < 2W |
| Electrical Lifespan | > 50000 times |
| Installation | DIN rail (35mm) |
| Operating Temperature | -35°C to +70°C |
| Relative Humidity | < 50% (at 40°C) |
| Dimensions | 36.5 x 78.7 x 66.5 mm |
| Color | White |
