Siemens 7KM2200-2EA40-1JA1 electric meter

Siemens PMD SENTRON PAC2200 DIN rail. Measuring functions: Power current, Units of measurement: kWh, International Protection (IP) code: IP40. Maximum current: 65 A. Weight: 540 g, Package weight: 532 g, Package depth: 136 mm

SENTRON, measuring device, 7KM PAC2200, LCD, L-L: 400 V, L-N: 230 V, 65 A, strd rail instr., 3-phase, Modbus TCP + MID, apparent/active/ reactive energy, self-powered, screw terminals Energy counter SENTRON 7KM PAC2200 for calibrated measurement of the power consumption in single-phase and three-phase systems, e.g. in industrial plants, commercial buildings, offices and apartments in apartment blocks, for billing purposes. The 7KM PAC 2200 energy meters calibrated according to MID with an extended range of functions enable precise, reproducible and reliable measurement of energy values for infeed, outgoing feeders or individual loads by transformer measurement or direct measurement up to 65 A. They not only provide comprehensive information about your electrical installations and power distribution, but also key measured values for assessing the status of the plant. For further processing of the measured data, the devices are equipped with a wide range of communication options for easy integration into higher-level automation and energy management systems via Modbus TCP, PROFINET, Modbus RTU and M-Bus. The 7KM PAC measuring devices are available in different versions designed to match your requirements. SENTRON PAC - specialists in measured value acquisition.

Features

Measuring functions: Power current
Units of measurement: kWh
International Protection (IP) code: IP40

Power

Maximum current: 65 A

Weight & dimensions

Weight: 540 g
Package weight: 532 g
Package depth: 136 mm
Package width: 123 mm
Package height: 108 mm

Technical details

Compliance certificates: CE, RoHS, REACH
Feature: Factory-calibrated
Feature: Escapement mechanism
Nominal voltage (Un, n-l): 3-276 V
Nominal voltage (Un, l-l): 3-480 V
Feature: Lock code
Tariff type: Two-tariff
Energy type: Effective power and reactive power
Number of positions total (counter): 12
Pole type: Three conductor/four conductor
Number of modular spacings: 6
Interface type: Modbus
Nominal current (In): 65 A
Mounting method: DIN rail mounted
