Siemens 6AV2123-2GB03-0AX0 digital / analogue I / O module

Siemens SIMATIC HMI KTP700 Basic. Module type: Digital, Signal direction: Input, Supported network protocols: TCP/IP, SNMP, DCP, LLDP. Width: 214 mm, Height: 158 mm, Weight: 977 g. Country of origin: China

SIMATIC HMI, KTP700 Basic, Basic Panel, Key/touch operation, 7 TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic V13, contains open-source software, which is provided free of charge see enclosed CD Basic Panels are perfect for the cost-effective implementation of simple visualization tasks at machine level. Their basic features and functionality as well as an especially attractive price make them perfect entry-level devices.

Features

Module type: Digital
Signal direction: Input
Supported network protocols: TCP/IP, SNMP, DCP, LLDP
International Protection (IP) code: IP65
Product colour: Grey
Certification: cULusC-TICKKC IP65

Operational conditions

Operating temperature (T-T): 0 - 50 °C

Weight & dimensions

Width: 214 mm
Height: 158 mm
Weight: 977 g
Package width: 205 mm
Package depth: 276 mm
Package height: 78 mm
Package weight: 977 g

Technical details

Feature: Sustainability compliance
Compliance certificates: CE, RoHS, REACH

Logistics data

Country of origin: China
