Siemens 6AV2123-2DB03-0AX0 digital / analogue I / O module

Siemens SIMATIC HMI KTP400 Basic. Module type: Digital, International Protection (IP) code: IP65, Product colour: Grey. Width: 140 mm, Height: 116 mm, Weight: 459 g
SIMATIC HMI, KTP400 Basic, Basic Panel, Key/touch operation, 4 TFT display, 65536 colors, PROFINET interface, configurable from WinCC Basic V13/ STEP 7 Basic V13, contains open-source software, which is provided free of charge see enclosed CD Basic Panels are perfect for the cost-effective implementation of simple visualization tasks at machine level. Their basic features and functionality as well as an especially attractive price make them perfect entry-level devices.

Features

Module type: Digital
International Protection (IP) code: IP65
Product colour: Grey

Operational conditions

Operating temperature (T-T): 0 - 50 °C

Weight dimensions

Width: 140 mm
Height: 116 mm
Weight: 459 g
Package width: 128 mm
Package depth: 199 mm
Package height: 52 mm
Package weight: 458 g

Technical details

Compliance certificates: CE, RoHS, REACH
