Renogy Core Mini 12V 100Ah LiFePO battery

Renogy Core Mini 12V 100Ah LiFePO battery (12.8V, Group 22NF)

Renogy Core Mini 12.8V 100Ah (format Group 22NF ) is a compact LiFePO battery for campers, small trailers, boats, and off-grid installations. It combines high capacity with small dimensions and low weight, and thanks to the low-temperature charging cutoff, it protects the cells in winter. The side-mounting option makes it easy to install in tight storage spaces, and the housing IP65
and increased vibration resistance make the battery well-suited to mobile and marine conditions.

Key benefits

• Compact 22NF format - easy installation in small spaces (camper, boat, building).


• Safe charging in winter - charging cut-off at low temperature.


• High durability - okay. 5000 cycles at 80% DoD (80% EoL).


• High instantaneous power - 300 A for 5 sec for devices with high starting current.


• Terrain and water resistance - IP65 + design for mobile and marine applications (ABYC).


• Side mounting - use of narrow storage spaces and unusual spaces.


• Optional monitoring - when paired with Renogy 300A Shunt Remote viewing of parameters possible.


• Capacity scaling - series and parallel connection to 4S4P (up to approx. 20.48 kWh).

Main features

• Very compact housing (Group 22NF) with a capacity of 100Ah


• EV-class prismatic cells (UL)


• Frost charging cut-off to protect LiFePO


• IP65 housing for outdoor use


• Increased resistance to vibrations and mobile conditions


• High instantaneous current of 300A for starting loads

Technical specifications

• Model: Renogy Core Mini 12.8V 100Ah LiFePO


• Type: LiFePO (lithium iron phosphate)


• Nominal voltage: 12.8V


• Nominal capacity: 100 Ah (0.5C, 25°C)


• Operating voltage range: 10V - 14.8V


• Max charging current: 100 A


• Max discharge current: 100 A


• Peak discharge current: 300 A for 5 sec


• Cyclic life: 5000 cycles (80% DoD, 80% EoL; 0.5C, 25°C)


• Charging temperature range: 0°C - 50°C


• Discharge temperature range: -20°C - 60°C


• Storage temperature range: -25°C - 65°C


• Working humidity: 10% - 95%


• Connection method: in series and parallel (up to 4S4P)


• Clamp bolt size: M8 × 1.25 × 12 mm


• Recommended tightening torque: 10-12 N m


• Degree of protection: IP65


• Dimensions: 229 × 138 × 213 mm


• Libra: 9.9 kg

Contents of the set

• Long terminal screws (2 pcs): 2 × M8 × 1.25 × 15 mm

Warranty and certificates

• Guarantee: 5 years (proportional - materials and workmanship)


• Certificates: MSDS, UN38.3, FCC, CE, PSE, RCM, IC, RoHS, UKCA
