RACK SYSTEMS SM-35 / B mounting rails for Lanberg cabinets
Product reference: 39-SM-35/B

The SM-35/B mounting rails from RACK SYSTEMS are a robust and durable solution for 600 mm deep 19" rack cabinets. The set includes two rails measuring 38x350x38 mm and a mounting kit (4 cages with M6 screws and washers). The entire unit is finished in black (RAL9005). The product is covered by a 36-month warranty.

Szyny montażowe RACK SYSTEMS SM-35 / B do szaf Lanberg
Szyny montażowe RACK SYSTEMS SM-35 / B do szaf Lanberg
Szyny montażowe RACK SYSTEMS SM-35 / B do szaf Lanberg
Szyny montażowe RACK SYSTEMS SM-35 / B do szaf Lanberg
Szyny montażowe RACK SYSTEMS SM-35 / B do szaf Lanberg

RACK SYSTEMS SM-35 / B mounting rails for Lanberg cabinets

Product reference: 39-SM-35/B

The SM-35/B mounting rails from RACK SYSTEMS are a robust and durable solution for 600 mm deep 19" rack cabinets. The set includes two rails measuring 38x350x38 mm and a mounting kit (4 cages with M6 screws and washers). The entire unit is finished in black (RAL9005). The product is covered by a 36-month warranty.

You have 3 products in compare list, please remove someone and try again
  • Add to favorites products
  • Added to favorites products
  • Removed to favorites product
Add to compare
71,32 €
Product in warehouse

Guarantee
24 month

Delivery from Europe in
5 - 8
business days

Your message has been successfully sent!
Fill in the required fields*

RACK SYSTEMS SM-35/B mounting rails


High load capacity - up to 100 kg
SM-35/B rails are designed to support heavy equipment such as servers, UPSs, and network switches.
Solid construction made of 1.6 mm SPCC steel
The rails are mounted at two points to the rack rail, which simplifies installation and increases the rigidity of the entire structure.
Standard dimensions 350 mm
Rails with dimensions 38×350×38 mm fit most front-mounted devices in 19" RACK cabinets.
Mounting kit included
The rails come with a full assembly kit - 4 threaded cages, M6 screws and washers - which eliminates the need to purchase additional elements and speeds up installation.


Technical specifications:



  • Parameters / Model: SM-35/B RACK SYSTEMS

  • Material: SPCC Cold Rolled Steel Sheet

  • Material thickness: 1.6 mm

  • Color: black (RAL9005)

  • Load capacity: up to 100 kg

  • Dimensions: 38 × 350 × 38 mm (width / length / height)

  • Mounting: two-point, for rack rail

  • Mounting kit: included in the set

  • Accessories included: 4 baskets with M6 screw and washer




Main features:



  • Load capacity up to 100 kg

  • Made of 1.6 mm thick SPCC steel

  • Two-point rack rail mounting

  • Standard dimensions: 38 × 350 × 38 mm

  • Includes mounting kit (4x cage with M6 screw and washer)

  • Dedicated to Lanberg cabinets with a depth of 600 mm
