Power Supply - GIGABYTE P750BS 750W 80 PLUS Bronze 4x PCI-E 6+2 Pin ATX
Product reference:
14-4719331555238
750W 80 PLUS Bronze certified power supply with active cooling. It features four PCI-E 6+2 pin connectors, seven SATA power connectors, and a non-modular cable design.
Power Supply - GIGABYTE P750BS 750W 80 PLUS Bronze 4x PCI-E 6+2 Pin ATX
Product reference:
14-4719331555238
750W 80 PLUS Bronze certified power supply with active cooling. It features four PCI-E 6+2 pin connectors, seven SATA power connectors, and a non-modular cable design.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
GIGABYTE P750BS Power supply
750W power supply with 80 PLUS Bronze certification and active cooling. Features: four PCI-E 6+2 pin connectors, seven SATA power connectors and non-modular cable design.
- High efficiency class with 80 PLUS Bronze certification and 88% efficiency rating.
- Powerful 750W output with multiple protection mechanisms, including overvoltage and short circuit protection.
- Compact design with top-mounted 12cm fan for efficient cooling and quiet operation.
- Versatile connectivity with 7 SATA power connectors and multiple PCI Express power connectors for wider compatibility.
Design | |
|---|---|
| Product color | Black |
| On/Off switch | Yes |
| Fan location | Above |
| Fan diameter | 12 cm |
| Cooling type | Active |
| Number of fans | 1 pc. |
Power | |
| Power Good signal delay range | 100 - 150ms |
| Maximum output current (+5Vsb) | 3 A |
| Total power (-12V) | 3.6W |
| Maximum output current (+5V) | 20 A |
| AC input voltage | 200 - 240V |
| Total power (+5Vsb) | 15W |
| Shelf life | 16ms |
| Total power (+12V) | 750W |
| AC input frequency | 50/60Hz |
| Input current | 6 A |
| Total power (+3.3V) | 100W |
| Maximum output current (+3.3V) | 20 A |
| Maximum output current (+12V) | 62.5 A |
| Maximum output current (-12V) | 0.3A |
| Power factor correction (PFC) type | Active |
| Power factor | 0.9 |
| Efficiency | 88% |
Weight and dimensions | |
| Width | 150mm |
| Height | 86 mm |
| Depth | 140mm |
| Weight | 2.22 kg |
Operation | |
| 80 PLUS certificate | 80 PLUS Bronze |
| Mean Time Between Failures (MTBF) | 100000 hours |
| Bearing technology | FDB |
| Power supply unit (PSU) form factor | ATX |
| Purpose | PC |
Ports and interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 7 |
| PCI Express power connectors (6+2 pin) | 4 |
| Cable type | Non-modular |
| Height | 180mm |
| Length | 320mm |
| Weight | 3600 grams |
| Width | 220mm |
