Power Supply - Gigabyte P550B 550W 20+4 Pin ATX Black
Product reference:
14-4719331551490
The Gigabyte P550B power supply delivers 550W of power and is 80 PLUS Bronze certified. It features a non-modular design, active cooling with a 12cm fan, and multiple connectors, including 6 SATA and 2 PCI Express.
Power Supply - Gigabyte P550B 550W 20+4 Pin ATX Black
Product reference:
14-4719331551490
The Gigabyte P550B power supply delivers 550W of power and is 80 PLUS Bronze certified. It features a non-modular design, active cooling with a 12cm fan, and multiple connectors, including 6 SATA and 2 PCI Express.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
Gigabyte P550B 550W 20+4 Pin ATX Power Supply - Black
The Gigabyte P550B power supply provides 550 W of power with 80 PLUS Bronze certification. It has a non-modular design, active cooling with a 12 cm fan, and multiple connectors, including 6 SATA and 2 PCI Express.
- Power Output: Total power 550 W with combined power +12V 522 W.
- Cooling System: Active cooling with a top-mounted 12 cm fan for efficient heat dissipation.
- Protection Functions: Equipped with protections against overheating, low voltage, high current, short circuit, high voltage and overpower.
- 80 PLUS Certification: 80 PLUS Bronze certification ensures high energy efficiency (85% efficiency).
- Connectivity: Includes 6 SATA power connectors, 2 PCI Express connectors (6+2 pin) and a 20+4 pin ATX motherboard power connector.
Design | |
|---|---|
| Cooling type | Active |
| Fan location | Above |
| Fan diameter | 12 cm |
| On/off switch | Yes |
| Number of fans | 1 fan |
| Product color | Black |
Power | |
| Total power (+5Vsb) | 15W |
| Power protection functions | Overheating, Low voltage, High current, Short circuit, High voltage, Over power |
| Total power | 550W |
| Input current | 8 - 4 A |
| AC input voltage | 100 - 240V |
| Efficiency | 85% |
| Total power (-12V) | 3.6W |
| Power factor | 0.9 |
| Maximum output current (+5Vsb) | 3 A |
| Total power (+12V) | 522 W |
| Total power (+5V) | 108W |
| Maximum output current (+3.3V) | 18 A |
| Maximum output current (-12V) | 0.3A |
| Maximum output current (+5V) | 15 A |
| AC input frequency | 50 - 60 Hz |
| Shelf life | 16ms |
| Maximum output current (+12V) | 43.5 A |
| Power factor correction (PFC) type | Active |
| Total power (+3.3V) | 108W |
Weight and dimensions | |
| Width | 150mm |
| Depth | 140mm |
| Height | 86 mm |
Operation | |
| 80 PLUS certificate | 80 PLUS Bronze |
| Mean Time Between Failures (MTBF) | 100000 hours |
| Purpose | PC |
| Bearing technology | HDB |
| ATX version | 2.31 |
| Power supply unit (PSU) form factor | ATX |
Ports and interfaces | |
| ATX power connector (20+4 pin) | Yes |
| Number of SATA power connectors | 6 |
| SATA power cable length | 500mm |
| PCI Express power cable length | 55 cm |
| Cable type | Non-modular |
| Floppy drive connector | Yes |
| PCI Express connector | Yes |
| Motherboard power connector | 20+4 pin ATX |
| CPU power cable length | 60cm |
| Motherboard power cable length | 55 cm |
| Peripheral (Molex) power cable length | 500mm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| Floppy drive power connector | 1 |
| Height | 215 mm |
| Length | 255mm |
| Weight | 2050 grams |
| Width | 120mm |
