Power supply unit Cooler Master MWE Gold V2 1250W ATX 3.1 (MPE-C501-AFCAG-3EEU)

Total power: 1250W
Efficiency: 90 %
Power factor correction (PFC) type: Active
Hold time: 16 ms
Power protection description: Under voltage, Short circuit, Over voltage, Over total voltage, Overload, Over current
Total current (+3.3V): 120 W
Total current (+12V): 1248 W
Total current (+5V): 120 W
Total current (-12V): 3.6 W
Total current (+5Vsb): 15 W
Maximum output current (+3.3V): 20 A
Maximum output current (+12V): 104 A
Maximum output current (-12V): 0.3 A
Maximum output current (+5Vsb): 3 A
Input current: 15 - 7
AC input frequency: 50/60
AC input voltage: 100 - 240
Power good signal delay range: 100 - 150

Connectivity
Motherboard power connector: 24-pin ATX
ATX Power connector: Yes
Number of SATA power connectors: 12
Peripheral (Molex) power connectors (4-pin): 4
EPS power connector (8-pin): Yes
PCI Express power connector (6+2 pin): 3
Cable type: Fully modular
Motherboard power cable length: 650 mm
SATA power cable length: 860, 740, 620, 500
Peripheral (Molex) power cable length: 860, 500, 620, 740
EPS power connector (4+4 pins): Yes

Performance
Purpose, result: PC
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h
Cooler shaft type: TBB
ATX version: 3.1
Power supply unit (PSU) form factors Form factor: ATX

Design
Fan diameter: 140 mm
Number of fans: 1 fan
Cooling type: Active
Fan placement: Head
Integrated on/off switch: Yes
Product color: Black

Certificates
Certification: TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS

Technical information
Sustainability certificates: ErP

Weight & dimensions
Weight: 3.02 kg
Height: 86 mm
Width: 150 mm
Depth: 180 mm

Environmental conditions
Operating temperature range (TT): 0 - 50

Packaging information
Packaging weight: 3420 g
Packaging depth: 333 mm
Packaging height: 122 mm
Packaging width: 197 mm
Packaging type: Box
