LevelOne UPS-2101 uninterruptible power supply (UPS)

LevelOne UPS-2101. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 1000 W. AC outlet types: C13 coupler, AC outlets quantity: 8 AC outlet(s), USB port type: USB Type-B. Battery technology: Lead-Acid, Battery capacity: 7000 Ah, Battery voltage: 36 V. Form factor: Rackmount/Tower, Product colour: Black, Control type: Buttons. Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

The LevelOne Online UPS is the ultimate solution for dependable battery backup in both home and office settings. With an output power factor of 1.0, this UPS delivers maximum efficiency and performance. Designed for generator compatibility, it provides continuous power even during extended outages.Equipped with a HID-compatible USB connection for seamless device communication , the UPS offers both convenience and security.

The easybattery replacement feature simplifies maintenance, while the programmable outlet management allows you to tailor power distribution to meet your specific needs. Easy to install and operate, the LevelOne Online UPS provides a reliable and efficient way to protect your systems from power surges and failures, ensuring the uninterrupted operation of your critical equipment. The included rackmount ears support both rack mounting and tower installation, offering flexibility in setup.

Features

UPS topology: Double-conversion (Online)
Output power capacity: 1 kVA
Output power: 1000 W
Waveform: Sine
Input operation voltage (min): 160 V
Input operation voltage (max): 300 V
Input frequency: 50/60 Hz
Output operation voltage (min): 200 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Power factor: 1
Feature: Emergency Power Off (EPO)
Feature: Audible alarm(s)
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet types: C13 coupler
AC outlets quantity: 8 AC outlet(s)
Feature: USB port
USB 2.0 ports quantity: 1
USB port type: USB Type-B
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
RS-232 ports: 1
Ethernet LAN (RJ-45) ports: 1
Feature: Emergency Power Off (EPO) connector

Battery

Battery technology: Lead-Acid
Battery capacity: 7000 Ah
Battery voltage: 36 V
Number of batteries included: 3 pc(s)
Battery recharge time(90%): 3 h
Battery capacity: 84 Wh
Feature: Rechargeable battery

Design

Form factor: Rackmount/Tower
Product colour: Black
Control type: Buttons
Display type: LCD
International Protection (IP) code: IP20

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Packaging content

Feature: Batteries included
Feature: Rack mount kit
Cables included: Input power cable, USB cable
Feature: Manual
Feature: Quick installation guide

Weight & dimensions

Width: 438 mm
Depth: 445 mm
Height: 85.5 mm
Weight: 14 kg

Packaging data

Package type: Box
