GIGABYTE P750BS Power Supply - PCI-E 6+2 Pin x 4, 80 PLUS Bronze, 120mm Fan, ATX compatible, EU Plug
Product reference:
3-4719331555238
GIGABYTE P750BS Power Supply - PCI-E 6+2 Pin x 4, 80 PLUS Bronze, 120mm Fan, ATX compatible, EU Plug
GIGABYTE P750BS Power Supply - PCI-E 6+2 Pin x 4, 80 PLUS Bronze, 120mm Fan, ATX compatible, EU Plug
Product reference:
3-4719331555238
GIGABYTE P750BS Power Supply - PCI-E 6+2 Pin x 4, 80 PLUS Bronze, 120mm Fan, ATX compatible, EU Plug
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Lithuania in
3 - 8
business days
| Design | |
|---|---|
| Fan diameter | 12 cm |
| Number of fans | 1 fan |
| Cooling type | Active |
| On/off switch | Yes |
| Product colour | Black |
| Fan location | Top |
| Power | |
| Power protection features | Short circuit, Over voltage, Under voltage, Over current, Overheating, Over power |
| AC input voltage | 200 - 240V |
| Input current | 6 A |
| AC input frequency | 50/60Hz |
| Efficiency | 88% |
| Power factor | 0.9 |
| Total power | 750W |
| Max output current (-12V) | 0.3A |
| Hold time | 16ms |
| Max output current (+3.3V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Power Factor Correction (PFC) type | Active |
| Max output current (+5V) | 20 A |
| Combined power (+5V) | 100W |
| Max output current (+12V) | 62.5 A |
| Combined power (+5Vsb) | 15W |
| Combined power (-12V) | 3.6W |
| Combined power (+12V) | 750W |
| Power Good signal delay range | 100 - 150ms |
| Combined power (+3.3V) | 100W |
| Weight dimensions | |
| Height | 86 mm |
| Depth | 140mm |
| Weight | 2.22 kg |
| Width | 150mm |
| Performance | |
| 80 PLUS certification | 80 PLUS Bronze |
| Mean time between failures (MTBF) | 100000 hours |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | FDB |
| Packaging data | |
| Package type | Box |
| Package weight | 2.68 kg |
| Package width | 254 mm |
| Package depth | 206 mm |
| Package height | 117 mm |
| Ports interfaces | |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Floppy disk drive connector | Yes |
| PCI Express connector | Yes |
| Cabling type | Non-Modular |
| CPU power connector (4+4 pin) | Yes |
| ATX power connector (20+4 pin) | Yes |
| Number of SATA power connectors | 7 |
| PCI Express power connectors (6+2 pin) | 4 |
| Floppy drive power connector | 2 |
| Peripheral (Molex) power cable length | 600, 150 |
| Motherboard power cable length | 60cm |
| SATA power cable length | 150mm, 500 |
| Motherboard power connector | 20+4 pin ATX |
| Logistics data | |
| Warranty period | 3 years |
