FSP HYDRO PTM PRO 850W power supply unit

FSP Hydro PTM PRO 850W Power supply unit ATX ATX2.52 Black. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, CPU power cable length: 70 cm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: CPU, PCIe, Peripheral (Molex), SATA

The FSP Hydro PTM PRO series offers high efficiency and longevity to your PC build. Our proprietary conformal coating protects the power supply from dust, humidity, stains, and harsh environments. The Hydro PTM PRO has been designed to reliably operate at a relative humidity of up to 95%. It also features a semi-fanless eco mode that will suspend fan operation until the load has exceeded 30%. This feature can be controlled with the simple flick of a switch located next to the on/off button for easy access. This model also includes fully modular black ribbon cables for DIY enthusiasts looking to create cleaner builds. The FSP Hydro PTM PRO is a top-of-the-line power supply that delivers function, efficiency, and style making it a great addition to any system.

Power

Total power: 850 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 11 - 5.5 A
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 120 W
Combined power (+12V): 850 W
Combined power (+5V): 120 W
Combined power (-12V): 18.6 W
Combined power (+5Vsb): 18.6 W
Max output current (+3.3V): 20 A
Max output current (+12V): 70.83 A
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Efficiency: 92%
Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 60 cm
Number of SATA power connectors: 14
Peripheral (Molex) power connectors (4-pin): 5
PCI Express power connectors (6+2 pin): 8
Feature: CPU power connector (4+4 pin)
CPU power cable length: 70 cm
Feature: ATX power connector (20+4 pin)
Floppy drive power connector: 1
Feature: Floppy disk drive connector
Cabling type: Fully-Modular

Performance

80 PLUS certification: 80 PLUS Platinum
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.52
EPS version: 2.92
Bearing technology: FDB

Design

Product colour: Black
Cooling type: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Fan location: Top
Feature: On/off switch

Packaging content

Cables included: CPU, PCIe, Peripheral (Molex), SATA

Weight & dimensions

Width: 150 mm
Depth: 190 mm
Height: 86 mm

Logistics data

Harmonized System (HS) code: 84733020
