Epever TCP 306 Network Adapter

The Epever TCP 306 network adapter is an innovative device that enables communication with solar controllers, inverters, and hybrid chargers via an RS485 interface and the TCP protocol. This device enables remote monitoring and control of power system parameters, such as XTRA, Triron, and Tracer-AN (10-40A) controllers, IPower-Plus and IPT inverters, and HP-AL-S hybrid chargers. The adapter transmits data to the EPEVER cloud platform, allowing for comprehensive analysis and remote parameter adjustments, without requiring physical access to the devices.

Flexible communication and transmission speed

With a wide range of transmission speeds (from 600 bps to 230.4 Kbps), the TCP 306 adapter offers the flexibility to adapt communication to specific application requirements. The standard Ethernet port with an RJ45 interface supports various transmission speeds, allowing you to optimally adapt your network to your individual needs.
The adapter is configured using a PC-based tool, allowing you to conveniently change IP addresses, TCP server settings, client modes, and other network parameters. The installation process is intuitive and requires no advanced technical knowledge, making the device easy to use and manage.

Real-time parameter reading

Thanks to EPEVER TCP 306, users have access to real-time data, which allows for ongoing monitoring of system operation and making quick decisions in the event of changes in device operation.

EPEVER TCP 306 - Technical Parameters

• Operating voltage: 5V~36V DC


• Operating current:



  • 116 mA at 5V


  • 53 mA at 12V






• Connection type: RJ45, 10/100 Mbps, cross-direct adaptive


• Supported protocols: IP, TCP/UDP, ARP, ICMP, IPV4, HTTP


• Transmission speed: 600 bps ~ 230.4 kbps


• Operating modes:



  • TCP Server


  • TCP Client


  • UDP Server


  • UDP Client






• Delay: < 10 ms


• Operating temperature: -25 to 75


• Storage temperature: -40 to 105


• Humidity: ≤ 95% (non-condensing)


• Dimensions: 98.0mm x 86.0mm x 25.0mm


• Electromagnetic isolation: 1.5 kV


• Libra: 205 g

The EPEVER TCP 306 is a versatile network adapter that provides reliable communication with devices via an RJ45 interface and the TCP/UDP protocol. Supporting a wide operating voltage range (5V~36V DC) and transmission speeds from 600 bps to 230.4 kbps, the adapter adapts to a variety of applications. Its low latency (<10 ms) and support for both TCP and UDP modes make it an ideal solution for remote device monitoring and control.
