Eaton 5SC 1000i Rack2U (5SC1000IR)
Product reference:
3-0743172088321
Eaton 5SC 1000i Rack2U (5SC1000IR)
Eaton 5SC 1000i Rack2U (5SC1000IR)
Product reference:
3-0743172088321
Eaton 5SC 1000i Rack2U (5SC1000IR)
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
11 - 20
business days
UPS topology Line-Interactive | Output power capacity 1 kVA | Output power 700 W | Input operation voltage (min) 184 V | Input operation voltage (max) 276 V | Input frequency 45/55 Hz | Output frequency 50/60 Hz | AC outlet types C13 coupler | Power plug C14 coupler | USB port Yes | Serial interface Yes | Form factor Rackmount | Colour Black | Operating temperature (T-T) 0 - 40 °C | Weight 15 kg
| Summary: | Eaton 5SC1000IR. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 700 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 8 AC outlet(s). Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Certification: CE, CB report (TÜV). Safety: IEC / EN 62040-1, UL 1778 |
| Vendor Homepage: | https://www.eaton.com/gb/en-gb/skuPage.5SC1000IR.html |
| Category Code: | UPW |
| CnCode: | 85044095 |
| Unit Box Height: | 0.235 |
| Unit Box Length: | 0.54 |
| Unit Box Width: | 0.575 |
| Input frequency: | 45/55Hz |
| Input operation voltage (max): | 276V |
| Input operation voltage (min): | 184V |
| Noise level: | 45dB |
| Output frequency: | 50/60Hz |
| Output frequency regulation: | 45-55 Hz (50Hz system), 55-65Hz (60Hz system)Hz |
| Output operation voltage (max): | 240V |
| Output operation voltage (min): | 220V |
| Output power: | 700W |
| Output power capacity: | 1kVA |
| Power protection features: | Overdischarge |
| UPS topology: | Line-Interactive |
| AC outlet types: | C13 coupler |
| AC outlets quantity: | 8AC outlet(s) |
| Power plug: | C14 coupler |
| RS-232 ports: | 1 |
| Serial interface: | Yes |
| Serial interface type: | RS-232 |
| USB 2.0 ports quantity: | 1 |
| USB port: | Yes |
| Form factor: | Rackmount |
| Product colour: | Black |
| Rack capacity: | 2U |
| Operating temperature (T-T): | 0 - 40°C |
| Certification: | CE, CB report (TÜV) |
| Safety: | IEC / EN 62040-1, UL 1778 |
| Depth: | 405mm |
| Height: | 86.2mm |
| Weight: | 14960g |
| Width: | 440mm |
| Harmonized System (HS) code: | 85078000 |
| Output voltage: | 230V |
| Product Net Weight: | 14.96kg |
| Shipping Box Depth: | 54cm |
| Shipping Box Height: | 23.5cm |
| Shipping Box Weight: | 19kg |
| Shipping Box Width: | 57.5cm |
| Unit Calculated Volume: | 0.07297m³ |
| Unit Calculated Weight: | 19kg |
| Units per Shipping Box: | 1 |
