Eaton 5P 650i Rack 1U G2 (5P650IRG2)
Product reference:
3-3553340710292
Eaton 5P 650i Rack 1U G2 (5P650IRG2)
Eaton 5P 650i Rack 1U G2 (5P650IRG2)
Product reference:
3-3553340710292
Eaton 5P 650i Rack 1U G2 (5P650IRG2)
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
11 - 16
business days
UPS topology Line-Interactive | Output power capacity 0.65 kVA | Output power 520 W | Waveform Pure sine | Input operation voltage (min) 160 V | Input operation voltage (max) 294 V | Input frequency 40/70 Hz | Output frequency 50/60 Hz | Number of input phases 1 | Number of output phases 1 | Efficiency 98% AC outlet types C13 coupler | Power plug C14 coupler | USB port Yes | Battery technology Sealed Lead Acid (VRLA) | Form factor Rackmount | Color Black | Display type LCD | Operating temperature (TT) 0 - 35 °C | Rack mount kit Yes | Weight 8.6 kg
| Summary: | Eaton 5P650IRG2. UPS topology: Line-Interactive, Output power capacity: 0.65 kVA, Output power: 520 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 2 min, Typical backup time at half load: 9 min. Form factor: Rackmount, Product color: Black, Rack capacity: 1U. Certification: IEC/EN 62040-1, UL 1778, IEC/EN 62040-2, IEC/EN 62040-3 (Performance), CE, CB report (TUV) |
| Vendor Homepage: | https://www.eaton.com/gb/en-gb/skuPage.5P650IRG2.html |
| Category Code: | UPW |
| CnCode: | 85044095 |
| Unit Box Height: | 0.175 |
| Unit Box Length: | 0.59 |
| Unit Box Width: | 0.445 |
| ECO fashion: | From |
| Efficiency: | 98% |
| Input frequency: | 40/70Hz |
| Input operation voltage (max): | 294V |
| Input operation voltage (min): | 160V |
| Noise level: | 40dB |
| Number of input phases: | 1 |
| Number of output phases: | 1 |
| Output frequency: | 50/60Hz |
| Output operation voltage (max): | 240V |
| Output operation voltage (min): | 200V |
| Output power: | 520W |
| Output power capacity: | 0.65kVA |
| UPS topology: | Line Interactive |
| Waveform: | Pure movie |
| AC outlet types: | C13 coupler |
| AC outlets quantity: | 4AC outlet(s) |
| Power plug: | C14 coupler |
| RS-232 port: | 1 |
| USB 2.0 ports quantity: | 1 |
| USB port: | Yes |
| Automatic battery test: | Yes |
| Battery technology: | Sealed Lead Acid (VRLA) |
| Hot-swap battery: | Yes |
| Typical backup time at full load: | 2min |
| Typical backup time at half load: | 9min |
| Display type: | LCD |
| Form factor: | Rackmount |
| Product colour: | Black |
| Rack capacity: | 1U |
| Operating temperature (TT): | 0 - 35°C |
| Certification: | IEC/EN 62040-1, UL 1778, IEC/EN 62040-2, IEC/EN 62040-3 (Performance), CE, CB report (TUV) |
| Management card included: | From |
| Rack mount kit: | Yes |
| Safety: | IEC/EN 62040-1, UL 1778 |
| Depth: | 361mm |
| Height: | 43.2mm |
| Weight: | 8600g |
| Width: | 438mm |
| Bundled software: | Intelligent Power Software suite |
| Input connection type: | IEC C14 |
| Mac compatibility: | From |
| Nominal input voltage: | 230V |
| Nominal output voltage: | 230V |
| Model: | 5P Gen2 |
| Units per Shipping Box: | 1 |
| Unit Calculated Volume: | 0.04595m³ |
| Unit Calculated Weight: | 11.2kg |
