CyberPower PR750ELCDGR uninterruptible power supply (UPS)

CyberPower PR750ELCDGR. UPS topology: Line-Interactive, Output power capacity: 0.75 kVA, Output power: 675 W. AC outlet types: C13 coupler, Type F, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 2.5 min, Typical backup time at half load: 10.5 min. Form factor: Tower, Product colour: Black, Housing material: Metal. Compliance certificates: CE, RoHS
CyberPower PR750ELCDGR Line-Interactive UPS, with seamless Pure Sine Wave, provides the best power protection available for office system devices including PCs, workstations, networking devices, and peripherals. It's typically integrated in the back office, server room, and data center environment.
The UPS can be locally managed via USB or serial ports, or remotely managed via an SNMP Card (an optional Remote Management Card), allowing administrators and users unsurpassed flexibility to remotely access each UPS through the network to perform real-time monitoring, UPS configurations, and scheduled system shutdowns by using PowerPanel Management software.

Features

UPS topology: Line-Interactive
Output power capacity: 0.75 kVA
Output power: 675 W
Waveform: Pure sine
Input operation voltage (min): 150 V
Input operation voltage (max): 301 V
Input frequency: 50/60 Hz
Output operation voltage (min): 230 V
Output operation voltage (max): 230 V
Output frequency: 50/60 Hz
Automatic Voltage Regulation (AVR): Yes
Surge energy rating: 405 J
Response time: 4 ms
Heat dissipation: 75 BTU/h
Number of input phases: 1
Number of output phases: 1
Output power factor: 0.9
Emergency Power Off (EPO): Yes
EMI/RFI noise filtering: Yes
Surge protection: Yes
Power protection features: Overload
Audible alarm(s): Yes
Management protocols: SNMP/HTTP
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm

Ports interfaces

AC outlet types: C13 coupler, Type F
Power plug: C14 coupler
AC outlets quantity: 4 AC outlet(s)
USB port: Yes
USB port type: USB Type-B
Emergency Power Off (EPO) connector: Yes

Battery

Battery technology: Sealed Lead Acid (VRLA)
Number of batteries supported: 1
Typical backup time at full load: 2.5 min
Typical backup time at half load: 10.5 min
Battery recharge time: 8 h
Hot-swap battery: Yes

Design

Form factor: Tower
Housing material: Metal
Product colour: Black
Control type: Buttons
Display type: LCD
LED indicators: Battery replacement, Fault, Power

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m

Certificates

Compliance certificates: CE, RoHS

Packaging content

Manual: Yes

Sustainability

Sustainability compliance: Yes
Sustainability certificates: ENERGY STAR

Weight dimensions

Width: 136 mm
Depth: 349 mm
Height: 162 mm
Weight: 12.3 kg

Packaging data

Package width: 272 mm
Package depth: 486 mm
Package height: 283 mm
Package weight: 13.3 kg

Logistics data

Harmonized System (HS) code: 8504408590
Warranty period: 3 year(s)
Country of origin: China

Other features

Battery type: RBP0014
