CyberPower OLS3000ERT2UA uninterruptible power supply (UPS)

CyberPower OLS3000ERT2UA. UPS topology: Double-conversion (Online), Output power capacity: 2 kVA, Output power: 1800 W. AC outlet types: C13 coupler, Power plug: Type F, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 48 V. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Compliance certificates: CE, EAC, RoHS, Certification: CE, EAC

CyberPower OLS2000ERT2UA is a high-performance UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It's typically integrated in the back office, server room, and data center environment.

The UPS features color LCD panel for users to monitor power system and configure settings easily. This model can be used with compatible Extended Battery Modules (EBM) to prolong system runtime during power interruption. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users. The product also supports power management software to perform real-time monitoring and remote management.

Features

UPS topology: Double-conversion (Online)
Output power capacity: 2 kVA
Output power: 1800 W
Waveform: Pure sine
Input operation voltage (min): 190 V
Input operation voltage (max): 300 V
Input frequency: 50/60 Hz
Output operation voltage (min): 208 V
Output operation voltage (max): 240 V
Output frequency: 50/60 Hz
Output frequency regulation: 0.5 Hz
Output voltage regulation: 1%
Maximum current: 9 A
Surge energy rating: 363 J
Response time: 0 ms
Heat dissipation: 682 BTU/h
Efficiency (ECO mode): 95%
Power factor: 0.9
Input power factor: 0.99
Output power factor: 0.9
Crest factor: 3:1
Feature: ECO mode
Feature: Emergency Power Off (EPO)
Output voltage Total Harmonic Distortion (THD): 5%
Feature: EMI/RFI noise filtering
Feature: Surge protection
Power protection features: Overload
Feature: Audible alarm(s)
Audible alarm modes: Battery replacement, Low battery alarm, Overload alarm, Fault, Alarm when on battery

Ports & interfaces

AC outlet types: C13 coupler
Power plug: Type F
AC outlets quantity: 8 AC outlet(s)
Feature: USB port
USB port type: USB Type-B
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
RS-232 ports: 1
Modem (RJ-11) ports: 1
Ethernet LAN (RJ-45) ports: 1
Feature: Emergency Power Off (EPO) connector

Battery

Battery technology: Sealed Lead Acid (VRLA)
Battery capacity: 9 Ah
Battery voltage: 48 V
Number of batteries supported: 3
Number of batteries included: 2 pc(s)
Typical backup time at full load: 3.8 min
Typical backup time at half load: 13.1 min
Battery life (max): 5 year(s)
Battery recharge time: 4 h
Charging current: 1.5 A
Feature: Hot-swap battery
Replacement battery cartridge: RBP0157

Design

Form factor: Rackmount/Tower
Housing material: Metal
Rack capacity: 2U
Cable length: 1.5 m
Cooling type: Active
Feature: Built-in fan
Product colour: Black
Control type: Buttons
Display type: LCD

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 50 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): -20 - 50%
Operating altitude: 0 - 1500 m
Non-operating altitude: 0 - 1500 m

Certificates

Compliance certificates: CE, EAC, RoHS
Certification: CE, EAC

Packaging content

Feature: Batteries included
Feature: Rack mount kit
Cables included: Input power cable, USB cable
Feature: Manual

Weight & dimensions

Width: 438 mm
Depth: 430 mm
Height: 88 mm
Weight: 19.2 kg

Packaging data

Package width: 540 mm
Package depth: 550 mm
Package height: 230 mm
Package weight: 23.4 kg

Logistics data

Harmonized System (HS) code: 8504408590
Country of origin: China
