CyberPower CP700EIPFCRM1U uninterruptible power supply (UPS)

CyberPower CP700EIPFCRM1U. UPS topology: Line-Interactive, Output power capacity: 0.7 kVA, Output power: 420 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 2 min, Typical backup time at half load: 9.6 min. Form factor: Rackmount, Product colour: Black, Silver, Housing material: Metal. Compliance certificates: CE, RoHS

Features

UPS topology: Line-Interactive
Output power capacity: 0.7 kVA
Output power: 420 W
Waveform: Pure sine
Input operation voltage (min): 165 V
Input operation voltage (max): 271 V
Input frequency: 50/60 Hz
Output frequency: 50/60 Hz
Output frequency regulation: 3 Hz
Feature: Automatic Voltage Regulation (AVR)
Maximum current: 10 A
Surge energy rating: 450 J
Response time: 6 ms
Heat dissipation: 17 BTU/h
Number of input phases: 1
Number of output phases: 1
Power factor: 0.6
Power Factor Correction (PFC) type: Active
Feature: Surge protection
Feature: Audible alarm(s)
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Power source type: AC
Feature: Socket circuit breaker

Ports & interfaces

AC outlet types: C13 coupler
Power plug: C14 coupler
AC outlets quantity: 6 AC outlet(s)
Feature: Serial interface
Serial ports quantity: 1
Ethernet LAN (RJ-45) ports: 2

Battery

Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 2 min
Typical backup time at half load: 9.6 min
Battery recharge time: 8 h
Feature: Hot-swap battery
Feature: Rechargeable battery

Design

Form factor: Rackmount
Housing material: Metal
Cable length: 1.83 m
Product colour: Black, Silver
Display type: LCD
LED indicators: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m

Certificates

Compliance certificates: CE, RoHS

Packaging content

Feature: Quick installation guide

Sustainability

Feature: Sustainability compliance

Weight & dimensions

Width: 433 mm
Depth: 229.7 mm
Height: 44 mm
Weight: 8.3 kg

Packaging data

Package width: 530 mm
Package depth: 280 mm
Package height: 155 mm
Package weight: 9.02 kg

Other features

Battery type: RBP0019
Nominal output voltage: 230 V
Nominal input voltage: 220-240 V
Feature: Overload protection
