CyberPower CP1600EPFCLCD uninterruptible power supply (UPS)

CyberPower CP1600EPFCLCD. UPS topology: Line-Interactive, Output power capacity: 1.6 kVA, Output power: 1000 W. AC outlet types: Type F, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 2.6 min, Typical backup time at half load: 9.7 min. Form factor: Tower, Product colour: Black, Cable length: 1.83 m. Compliance certificates: CE, RoHS

CyberPower CP1600EPFCLCD with Pure Sine Wave output safeguards mid- to high-end computer systems, servers and networking hardware that use conventional and Active Power Factor Correction (PFC) power supplies. Designed with GreenPower UPS™ Technology to improve UPS operating efficiency and to minimize its energy consumption, this UPS delivers significant energy cost savings over conventional UPS systems.

The UPS provides Automatic Voltage Regulation (AVR) to maintain stable voltage for connected equipment. The product features data line protection with high-speed transmission to safeguard communication equipment against surges/spikes as well as supply 1Gbps speed to transmit data. With tiltable color LCD panel , users can monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and configuration.

Features

UPS topology: Line-Interactive
Output power capacity: 1.6 kVA
Output power: 1000 W
Waveform: Pure sine
Input operation voltage (min): 169 V
Input operation voltage (max): 271 V
Input frequency: 50/60 Hz
Output operation voltage (min): 230 V
Output operation voltage (max): 230 V
Output frequency: 50/60 Hz
Feature: Automatic Voltage Regulation (AVR)
Maximum current: 10 A
Surge energy rating: 405 J
Response time: 8 ms
Heat dissipation: 24 BTU/h
Power Factor Correction (PFC) type: Active
Feature: Surge protection
Power protection features: Overload
Feature: Audible alarm(s)
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Power source type: AC
Feature: Detachable power cord
Feature: Socket circuit breaker

Ports & interfaces

AC outlet types: Type F
Power plug: C14 coupler
AC outlets quantity: 6 AC outlet(s)
Feature: USB port
USB 2.0 ports quantity: 2
USB port type: USB Type A/USB Type-C
Feature: Serial interface
Serial ports quantity: 1
Ethernet LAN (RJ-45) ports: 2

Battery

Battery technology: Sealed Lead Acid (VRLA)
Number of batteries supported: 1
Typical backup time at full load: 2.6 min
Typical backup time at half load: 9.7 min
Battery recharge time: 8 h
Replacement battery cartridge: RBP0142

Design

Form factor: Tower
Cable length: 1.83 m
Product colour: Black
Control type: Buttons
Display type: LCD
LED indicators: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m

Certificates

Compliance certificates: CE, RoHS

Packaging content

Feature: Batteries included
Feature: Quick installation guide

Sustainability

Feature: Sustainability compliance

Weight & dimensions

Width: 100 mm
Depth: 355 mm
Height: 280 mm
Weight: 11 kg

Packaging data

Package width: 195 mm
Package depth: 466 mm
Package height: 370 mm
Package weight: 13 kg

Logistics data

Harmonized System (HS) code: 8504408590
Country of origin: China

Other features

Nominal output voltage: 230 V
Nominal input voltage: 220-240 V
Feature: Overload protection
