COUGAR CGR-PR-1200 power supply unit

COUGAR Polar 1200W Power Supply ATX3.1 / 80 Plus Platinum / Modular. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, 80 PLUS certification: 80 PLUS Platinum, Mean time between failures (MTBF): 100000 h. Product colour: Silver, Fan diameter: 13.5 cm. Cables included: CPU, PATA, PCIe, SATA

To curb global warming, a PSU with higher efficiency means the longevity and less energy goes to waste. The COUGAR Polar platinum efficiency series protects the Earth and makes the best for the next generation.

COUGAR will present the first Platinum efficiency PSU Series, POLAR 1200 and 1050. The 100% Japanese capacitors and 50°C ambient operations with LLC, DC-DC structure generate an environmentally friendly PSU with high-efficiency performance. The fine-tune HDB fan with zero noise mode will also provide the perfect experience for all users in different conditions.

The Polar series is also certified as PLATINUM efficiency rating from Cybenetics Lab.

EVERY OUTPUT IS WORTH SAVING
Save the Earth with Lesser Energy Loss
- The Polar series will reduce the energy waste below 7%.
- With 80Plus Platinum certified to provide the efficiency level up to 92% at 115Vac.
- Less efficiency loss with streamlined board-to-board wave soldering.

ULTRA-SILENCE AT HIGH OUTPUT
Lower Heat Emission for Steady Temperature

- Zero noise mode at 40% loading silent.
- Automatic thermal control to provide an optimal speed-noise ratio.

Using COUGAR's 135mm HDB silent fan and large inhalation punched hole, the advanced frame increase the concentration of airflow and its fan curvature has been fine-tuned to reduce vibration.The overall fan combination leads to reaching the low fan noise A+ level, tested by Cybenetics Lab.

REFIND ELECTRONIC SOLUTION
Reduce the E-waste for the Next Generation

- 100% premium Japanese capacitor to prolong the longevity.
- Optimally perform in 50ºC working temperature environments.
- Tight 2% voltage regulation for ultra-stable operation.
- Hybrid Dynamic Bearing (HDB) fan to expand the durability.
- Patented groove design
- Centralized oil pressure
- No oil leakage
- Improved stability
- Less friction and noise
- Extended lifespan

Perfectly Support GeForce RTX™ 30 Series GPU
The POLAR series is designed for high end gamers and complicated media workers which can perfectly supporting RTX 30 series GPU and provide stable performance.

Power

Total power: 1200 W
AC input voltage: 100 - 240 V
AC input frequency: 47 - 63 Hz
Input current: 15 - 7 A
Combined power (+3.3V): 100 W
Combined power (+12V): 1200 W
Combined power (+5V): 100 W
Combined power (-12V): 3.6 W
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 20 A
Max output current (+12V): 100 A
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Efficiency: 92%
Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector: 20+4 pin ATX
Number of SATA power connectors: 12
Peripheral (Molex) power connectors (4-pin): 4
PCI Express power connectors (6+2 pin): 9
Feature: CPU power connector (4+4 pin)
Cabling type: Fully-Modular

Performance

80 PLUS certification: 80 PLUS Platinum
Purpose: PC
Feature: Silent mode
Mean time between failures (MTBF): 100000 h

Design

Product colour: Silver
Fan diameter: 13.5 cm

Packaging content

Cables included: CPU, PATA, PCIe, SATA

Weight & dimensions

Width: 180 mm
Depth: 150 mm
Height: 86 mm
Weight: 2.09 kg

Packaging data

Package width: 331 mm
Package depth: 229 mm
Package height: 107 mm
Package weight: 3.59 kg
