BlueSolar PWM-Light 48V-30A

BlueSolar PWM-Light Charger 48V-30A

This advanced charge controller, designed by Victron Energy, is designed for 48V photovoltaic systems. It is a reliable device that ensures optimal battery charging in solar systems, both at home and in mobile environments such as campers and boats.

Main product features:

1. Efficient battery charging: The BlueSolar PWM-Light 48V-30A enables fast and safe battery charging using PWM (Pulse Width Modulation) technology. This ensures even charging and preserves battery longevity by minimizing the risk of overcharging.


2. Performance and reliability: Thanks to its robust design, the controller can handle 48V systems with a maximum charging current of up to 30A. This makes it an ideal solution for medium-sized photovoltaic installations.


3. Simple installation and operation: The product is easy to install in photovoltaic systems thanks to its intuitive design. Its compact dimensions and user-friendly interface make installation and configuration hassle-free, even for novice users.


4. System protection: BlueSolar PWM-Light offers a range of safety features, such as short circuit, overcharge and reverse polarity protection, ensuring the safety of both the user and the photovoltaic system.


5. Versatility: The regulator is compatible with various battery types, including lead-acid (AGM, gel) and gel batteries. This allows it to be used in a wide range of energy systems.

Technical specifications:

• Parameters / Model: BlueSolar PWM-Light 48V-30A


• Input voltage (V): 48V


• Maximum charging current: 30A


• Charging technology: PWM (Pulse Width Modulation)


• Maximum system voltage: 60V


• Operating temperature range: -20°C to +50°C


• Overcharge protection: Yes


• Reverse polarity protection: Yes


• Short circuit protection: Yes


• Maximum input voltage: 60V


• Battery type: Lead-acid, AGM, gel


• Charging voltage temperature coefficient: -0.29%/°C


• Efficiency: 98%


• Charging regulation: 3-stage (absorption, float, bulk)


• No-load load: < 30mA


• Connection type: MC4


• Interface: LED (charging indicator)


• Device dimensions (width x height x depth): 160mm x 90mm x 45mm


• Libra: 0.5 kg


• Panel input: 1 entry


• Battery output: 1 output


• Certificates: CE, RoHS


• Charging voltage range: 48V DC


• Case: Plastic, shock- and moisture-resistant


• Installation: Wall mounting

Ideal for small and medium-sized photovoltaic installations, both in home and mobile environments (campers, boats).
BlueSolar PWM-Light 48V-30A This advanced charge controller, designed by Victron Energy, is designed for 48V photovoltaic systems. It's an excellent choice for those seeking an efficient and safe solution for managing solar energy in photovoltaic systems. Thanks to its high efficiency, ease of use, and reliability, this product ensures effective battery charging regardless of conditions. It's an investment that will help you fully utilize the potential of solar energy in any system.
