Blue Smart IP67 Charger 24/8 (1)

The Blue Smart IP67 24V/8A charger from Victron Energy is an advanced device characterized by high efficiency and durability, ideal for charging batteries in harsh environments. The device is Bluetooth-enabled, allowing full control and monitoring of the charging process via smartphone. This provides the convenience and flexibility necessary in today's dynamic environment.

Innovative Bluetooth management feature

The Blue Smart IP67 offers full control over the charging process thanks to a built-in Bluetooth module. Using the smartphone app, users can continuously monitor and adjust all parameters, ensuring precise battery charging management.

Advanced battery regeneration functions

The charger features advanced recovery for deeply discharged batteries. When the battery is almost completely drained, the Blue Smart IP67 uses a special low-current charging mode to safely restore it to full capacity.

Seven-step charging algorithm

To ensure maximum battery performance and durability, the charger utilizes an intelligent seven-stage charging algorithm. This algorithm optimizes the charging process at various stages, extending battery life and maintaining its efficiency at the highest level.

Power Saving Mode and Battery Longevity

The storage function automatically lowers the voltage after 24 hours of inactivity, minimizing energy consumption and preventing damage from corrosion of the battery plates. Additionally, the charger raises the voltage once a week to prevent sulfation and electrolyte stratification, a leading cause of premature battery failure.

Excellent performance and energy efficiency

The Blue Smart IP67 charger boasts an exceptional 96% efficiency, generating minimal heat. This makes it more energy-efficient, consuming less than one watt of power per charge, making it more environmentally friendly than standard chargers.

Durable construction for extreme conditions

The charger's housing is made of solid aluminum, making it resistant to water, shock, and dirt. Thanks to its IP67 rating, the charger is fully protected against external factors such as moisture, oil, and dust. The electronics are additionally protected with a layer of resin, ensuring long-term, trouble-free operation.

LiFePO4 battery support

The Blue Smart IP67 is fully compatible with lithium iron phosphate (LiFePO4) batteries, making it a versatile solution for a variety of battery types. Charging modes for these batteries can be easily selected with a single button.

Technical specifications:

• Input voltage range and frequency: 180-265 VAC, 45-65 Hz


• Efficiency: 96%


• No-load power consumption: 0.5 W


• Absorption charging voltage:



  • Normal: 28.8V


  • High: 29.4V


  • Li-ion: 28.4V






• Float charging voltage:



  • Normal: 27.6V


  • High: 27.6V


  • Li-ion: 27.0V






• Storage charging voltages:



  • Normal: 26.4V


  • High: 26.4V


  • Li-ion: 27.0V






• Charging current, normal mode: 8 A


• Charging current, low (LOW): 3 A


• Loading algorithm: 5-step adaptation


• Can be used as a power supply: Yes


• Security:



  • Reverse battery polarity (fuse)


  • Output short circuit


  • Excessive temperature






• Operating temperature range: from -30°C to +60°C (full rated power up to 40°C, 3% reduction for each °C above 40°C)


• Humidity: up to 100%


• Start abort option (Si): Yes


• Short circuit resistance, current limitation: 0.5 A


• Output voltage: maximum one volt lower than the main output


• Housing material and color: Aluminum, blue RAL 5012


• Battery connection: Black and red cable, 1.5 meters long


• Connection to 230 V AC: 1.5 metre cable with CEE 7/7 plug


• Protection category: IP67


• Libra: 2.4 kg


• Dimensions (H x W x D): 99 x 219 x 65 mm

The Blue Smart IP67 24V/8A is a unique battery charging tool that combines reliability, efficiency and modern technologies, ideal for use in harsh conditions both on land and at sea.
