Battery Protector SRNE IP65 60A

This advanced battery protection device is ideal for off-grid applications, such as in RVs, boats, and other outdoor recreational installations. Its IP65 rating makes it dust and water resistant, making it suitable for use in harsh weather conditions.
The device provides comprehensive battery protection against overload, deep discharge, overcharge, and reverse flow, significantly increasing battery safety and longevity. It supports various system voltages (12V, 24V, 36V, and 48V), making it a universal solution for various energy system configurations.
Built-in Bluetooth support allows users to monitor and control battery parameters in real time via a mobile app. This feature allows users to track voltage, charging current, protection level, and receive notifications of potential system issues.
The device is compatible with various battery types, including lead-acid (AGM, GEL) and lithium-ion (LiFePO4). Highly integrated features mean the Battery Protector SRNE combines monitoring, charge management, and protection in a single device, allowing for more efficient space management and a reduction in the number of required components.
Additional features include:

• Dual MOS circuit to prevent backflow.


• Support for TTL communication compliant with the Modbus protocol.


• Comprehensive multi-stage PWM charging management optimizes performance and extends battery life.


• Exclusive BMS double activation feature for Li-ion batteries.


• Large, easy-to-read LCD display and simple installation.

Specification

Parameters / Model PB4860N25

Electrical characteristics

• Nominal battery voltage: 12/24/36/48Vdc


• Operating voltage range: 8V - 70V


• System withstand voltage: 250V


• Rated current: 60A

Communication

• Standard communication: TTL


• Optional communication: Bluetooth

General

• Libra: 850 g


• Dimensions: 149 × 96.5 × 60 mm


• Degree of protection: IP65


• Operating temperature range: -35°C ~ 65°C


• Cooling mode: Natural heat dissipation

Certificates

• RoHS: Yes

is the perfect solution for users looking for a reliable, versatile protective device that provides the highest level of safety and functionality in a variety of conditions and applications.
