Battery Protector SRNE IP65 100A

This advanced battery protection device is designed specifically for off-grid systems. It's the ideal solution for those using renewable energy in environments that require reliable battery protection, such as campers, boats, and other outdoor installations. With an IP65 rating, the device is dust and water resistant, making it ideal for use in harsh weather conditions.
Main protection functions include overload, over-discharge, and reverse flow protection, ensuring battery longevity and power system stability. It supports various system voltages (12V, 24V, 36V, 48V), making the device versatile in many applications.
The device is equipped with Bluetooth, which enables remote monitoring and control of parameters such as voltage, charging current, and battery protection level via a mobile app. Users also receive notifications of any system problems, increasing comfort and safety of operation.
Key features:

• Supports various battery types, including lead-acid (AGM, GEL) and lithium-ion (LiFePO4).


• Ease of installation and operation, thanks to the large LCD display.


• Dual MOS circuit prevents backflow, providing additional protection.


• Supports TTL communication compliant with the Modbus protocol, which enables integration with other systems.


• Comprehensive PWM charging management in multiple stages, which optimizes the charging process and increases the battery life.


• Exclusive BMS double activation feature for lithium-ion batteries.


• Supports various load operating modes to adapt to different user needs.

The device combines monitoring, charge management, and protection functions into a single unit, simplifying installation and space management in electrical cabinets. This allows users to more easily manage the entire system by reducing the number of required components.

Specification

Parameters / Model PB4860N25

Electrical characteristics

• Nominal battery voltage: 12/24/36/48Vdc


• Operating voltage range: 8V - 70V


• System withstand voltage: 250V


• Rated current: 60A

Communication

• Standard communication: TTL


• Optional communication: Bluetooth

General

• Libra: 850 g


• Dimensions: 149 × 96.5 × 60 mm


• Degree of protection: IP65


• Operating temperature range: -35°C ~ 65°C


• Cooling mode: Natural heat dissipation

Certificates

• RoHS: Yes

is reliable protection that ensures safe and efficient use of batteries in various conditions, with the full support of advanced monitoring and protection technology.
