Power supply unit Gigabyte Aorus Elite Platinum ATX 3.1 1000W (GP-AE1000PM PG5 ICE)
Product reference:
3-4719331554651
Power supply unit Gigabyte Aorus Elite Platinum ATX 3.1 1000W (GP-AE1000PM PG5 ICE)
Power supply unit Gigabyte Aorus Elite Platinum ATX 3.1 1000W (GP-AE1000PM PG5 ICE)
Product reference:
3-4719331554651
Power supply unit Gigabyte Aorus Elite Platinum ATX 3.1 1000W (GP-AE1000PM PG5 ICE)
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
10 - 15
business days
Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.
- ATX 3.0 and PCIe Gen 5.0 ready (compatible with ATX 3.1)
- 80 PLUS Platinum certified
- 100% Japanese capacitors
- 120mm smart Fluid Dynamic Bearing (FDB) fan
- Compact design
- Fully modular design
- Powerful single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection
- 10 years warranty
| Summary: | GIGABYTE AORUS ELITE P1000W ICE Power Supply Unit - PCIe 5.0, 80 PLUS Platinum, Fully modular design, 120mm Fan, ATX 3.0 compatible, EU Plug. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: White, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm |
| Vendor Homepage: | https://www.gigabyte.com/uk/Power-Supply/GP-AE1000PM-PG5-ICE-rev-10#kf |
| Category Code: | PSU |
| CnCode: | 85044095 |
| Unit Box Height: | 0.205 |
| Unit Box Length: | 0.34 |
| Unit Box Width: | 0.12 |
| AC input frequency: | 50/60Hz |
| AC input voltage: | 100 - 240V |
| Combined power (+12V): | 999.6W |
| Combined power (+3.3V): | 125W |
| Combined power (+5V): | 125W |
| Combined power (+5Vsb): | 15W |
| Combined power (-12V): | 3.6W |
| Efficiency: | 92% |
| Hold time: | 16ms |
| Input current: | 15 - 6.5A |
| Max output current (+12V): | 83.3A |
| Max output current (+3.3V): | 25A |
| Max output current (+5V): | 25A |
| Max output current (+5Vsb): | 3A |
| Max output current (-12V): | 0.3A |
| Power factor: | 0.9 |
| Power Factor Correction (PFC) type: | Active |
| Power Good signal delay range: | 100 - 150ms |
| Power protection features: | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage |
| Total power: | 1000W |
| ATX power connector (20+4 pin): | Yes |
| Cabling type: | Fully-Modular |
| CPU power connector (4+4 pin): | Yes |
| Floppy disk drive connector: | Yes |
| Floppy drive power connector: | 2 |
| Motherboard power cable length: | 650mm |
| Motherboard power connector: | 20+4 pin ATX |
| Number of SATA power connectors: | 6 |
| PCI Express connector: | Yes |
| PCI Express power connectors (6+2 pin): | 6 |
| Peripheral (Molex) power connectors (4-pin): | 4 |
| 80 PLUS certification: | 80 PLUS Platinum |
| ATX version: | 3.1 |
| Bearing technology: | Ball bearing |
| Mean time between failures (MTBF): | 100000h |
| Power supply unit (PSU) form factor: | ATX |
| Purpose: | PC |
| Cooling type: | Active |
| Fan diameter: | 120mm |
| Fan location: | Top |
| Number of fans: | 1fan(s) |
| On/off switch: | Yes |
| Product colour: | White |
| Depth: | 140mm |
| Height: | 86mm |
| Weight: | 3102g |
| Width: | 150mm |
| Package depth: | 206mm |
| Package height: | 120mm |
| Package type: | Box |
| Package weight: | 3732g |
| Package width: | 340mm |
| Warranty period: | 10year(s) |
| Model name: | AORUS ELITE P1000W ICE Power Supply Unit - PCIe 5.0, 80 PLUS Platinum, Fully modular design, 120mm Fan, ATX 3.0 compatible, EU Plug |
| Units per Shipping Box: | 5 |
| Unit Calculated Volume: | 0.01086m³ |
| Unit Calculated Weight: | 3.73kg |
