CTK Electro 3.0 Box - lightweight damping mat 12 pcs / 2.2 m2

CTK Electro 3.0 Box - lightweight anti-vibration mats for electric cars 3 mm / 12 sheets CTK Electro 3.0 Box This is a high-quality, lightweight anti-vibration mat designed to effectively dampen vibrations, noise, and acoustic resonances in electric and hybrid cars, as well as any vehicle where the low weight of additional soundproofing materials is important. The package includes: 12 sheets measuring 370 × 500 mm, which gives a total area 2.22 m² The material is made from an innovative composite of high-quality butyl rubber, specialized polymers, and 100 µm-thick aluminum foil. This allows the CTK Electro 3.0 to combine high damping efficiency with low weight, excellent adhesion, and easy installation. Highly effective soundproofing at a low weight. The CTK Electro 3.0 was designed for electric and hybrid cars, where reducing additional weight is crucial. The mat effectively dampens body vibrations, sheet metal resonances, and road noise, while maintaining a favorable surface weight. The material weighs 3.89 kg/m², therefore CTK Electro 3.0 is a good choice for places where higher efficiency is needed than in the case of thinner mats, but we still want the soundproofing to be as light as possible. High damping factor MLF = 0.56 One of the most important parameters of anti-vibration mats is the mechanical loss factor MLF. The higher the value, the more effectively the material absorbs vibration energy and limits resonances. CTK Electro 3.0 achieves a value MLF = 0.56, which translates to very high soundproofing efficiency at a thickness of 3 mm. The mat is suitable for soundproofing doors, trunk, roof, floor, wheel arches, fenders, engine hood, and tailgate. High adhesion and easy installation. CTK Electro mats are self-adhesive, flexible, and easy to apply. The material adapts well to both flat and profiled surfaces. It does not require heating during standard installation, and the highest work comfort is achieved at ambient temperatures above +10°C. The butyl layer has self-vulcanizing properties. Several or several dozen hours after application, the material's adhesion to the substrate increases further, creating a durable and stable bond. Key advantages of CTK Electro 3.0 Box

• lightweight premium anti-vibration mat,
• designed for electric and hybrid cars,
• very effective damping of vibrations, noise and resonances,
• total thickness 3.0 mm,
• 100 µm thick aluminum foil,
• high vibration damping factor MLF = 0.56,
• low weight in relation to effectiveness,
• high initial adhesion to the substrate,
• even stronger bond after the self-vulcanization period,
• flexible structure for easy assembly,
• does not require heating,
• waterproof and anti-corrosion,
• without bitumen, tar and asphalt,
• non-toxic and odorless,
• suitable for automotive and indoor use.

In-car useCTK Electro 3.0 Box can be used on, among others:

• door,
• roof,
• trunk,
• floor,
• outer wheel arches,
• inner wheel arches,
• fenders,
• engine hood,
• trunk lid,
• body parts susceptible to resonance.

The product also works well for installing car audio systems. Soundproofing doors with CTK Electro 3.0 mat helps reduce sheet metal vibrations, improve the stability of the mounting surface, and achieve better speaker performance. Installation: Before installation, the surface should be dry, clean, and very well degreased. Cut the sheet to the desired shape, peel off the adhesive backing, and adhere the mat to the prepared surface. After applying, press the material firmly against the entire surface, preferably using a roller. The mat should adhere completely to the surface without air bubbles. The most comfortable installation is achieved at temperatures above +10°C. Basic parameters

• Product: lightweight self-adhesive anti-vibration mat
• Model: CTK Electro 3.0 Box
• Total thickness: 3.0 mm +/- 0.2 mm
• Aluminum foil thickness: 0.1 mm / 100 µm
• Material: composite of butyl rubber, specialized polymers and aluminum
• Mechanical loss factor MLF: 0.56
• Dimensions of 1 sheet: 370 × 500 mm
• Area of 1 sheet: 0.185 m²
• Quantity per package: 12 sheets
• Total packaging area: 2.22 m²
• Net weight of the package: 8.64 kg
• Surface weight: 3.89 kg/m²
• Recommended installation temperature: from +10°C to +40°C
• Operating temperature range: -40°C to +100°C
• Properties: anti-vibration, anti-corrosion, sealing, waterproof
