TERRA EU1000138 PC / workstation

TERRA EU1000138. Processor family: Intel® Core™ i3, Processor model: i3-12100. Internal memory: 8 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 500 GB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 730. Power supply: 350 W. Chassis type: Mini Tower. Product type: PC. Weight: 7 kg

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i3
Processor generation: 12th gen Intel® Core™ i3
Processor model: i3-12100
Processor cores: 4
Processor boost frequency: 4.3 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor socket: LGA 1700

Memory

Internal memory: 8 GB
Maximum internal memory: 96 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 8 GB
Memory slots: 2x DIMM
Memory clock speed: 5600 MHz

Storage

Total storage capacity: 500 GB
Storage media: SSD
Optical drive type: No
SSD capacity: 500 GB
NVMe: Yes
SSD form factor: M.2
Storage options: 4x SATA 6Gb/s ports, 1x M.2 slot (Key M) (supports PCIe 3.0 x4)
RAID support: No

Graphics

On-board graphics card: Yes
On-board graphics card model: Intel UHD Graphics 730
Resolution description: HDMI 4K @60Hz ¦ DP 4K @60Hz

Performance

Market positioning: Business
Motherboard chipset: Intel H610
Trusted Platform Module (TPM): Yes
Product type: PC
Trusted Platform Module (TPM) version: 2.0
Audio output channels: 8.0 channels

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 100,1000 Mbit/s
LAN controller: Intel I219V

Ports interfaces

USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
PS/2 ports quantity: 2

Expansion slots

Expansion slots: 1x PCIe 4.0 x16 Slot ¦ 1x PCIe 3.0 x1 Slot

Power

Power supply: 350 W
Power supply input voltage: 230 V
Power supply input frequency: 50 Hz
Power consumption (standby): 1.2 W
Power consumption (off): 0.25 W
80 PLUS certification: 80 PLUS Bronze

Design

Chassis type: Mini Tower

Software

Operating system installed: No
Compatible operating systems: Windows 10, Windows 11

Audio

Audio system: High Definition Audio

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 10 - 75%

Weight dimensions

Width: 180 mm
Depth: 384 mm
Height: 375 mm
Weight: 7 kg

Packaging content

Mouse included: Yes
Cables included: AC

Features

Motherboard manufacturer: ASUS Prime H610M-A

Other features

Locale: International repository
