TERRA 1000166 PC / workstation

TERRA 1000166. Processor family: Intel® Core™ i7, Processor model: i7-14700. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Operating system installed: Windows 11 Pro. Power supply: 400 W. Chassis type: Midi Tower. Product type: PC. Weight: 8 kg. Product colour: Black

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i7
Processor generation: Intel® Core™ i7 (14th gen)
Processor model: i7-14700
Processor cores: 20
Processor threads: 28
Processor boost frequency: 5.4 GHz
Performance cores: 8
Efficient cores: 12
Performance-core Max Turbo Frequency: 5.3 GHz
Efficient-core Max Turbo Frequency: 4.2 GHz
Performance-core base frequency: 2.1 GHz
Efficient-core base frequency: 1.5 GHz
Processor cache: 33 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor socket: LGA 1700
Processor base power: 65 W
Maximum turbo power: 219 W

Memory

Internal memory: 16 GB
Maximum internal memory: 128 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 8 GB
Memory slots: 4x DIMM
Memory clock speed: 5600 MHz

Storage

Total storage capacity: 1 TB
Storage media: SSD
Optical drive type: No
Number of storage drives supported: 6
SSD capacity: 1 TB
SSD interface: PCI Express 4.0
SSD form factor: M.2
Storage options: 2x M.2 (Key M) 2280/2260/2242, PCIe 4.0 x4 mode, 4x SATA 6Gb/s ports ¦ Supports SATA Raid, no NVMe Raid
Feature: RAID support
RAID levels: 1, 0, 10

Graphics

Feature: On-board graphics card
Discrete graphics card model: Not available
On-board graphics card model: Intel UHD Graphics 770
Resolution description: DisplayPort 1.2 max. 4096 x 2304@60Hz ¦ HDMI 2.1 max. 4096 x 2160@60Hz ¦ D-Sub (VGA) max. 1920 x 1200@60Hz

Performance

Market positioning: Business
Motherboard chipset: Intel B760
Feature: Trusted Platform Module (TPM)
Product type: PC
Trusted Platform Module (TPM) version: 2.0
Audio output channels: 8.0 channels
Sound pressure level: 24 dB

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 100,1000 Mbit/s

Ports & interfaces

USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPorts quantity: 2
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) ports quantity: 1

Expansion slots

PCI Express x1 slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Expansion slots: 1x PCIe 4.0/3.0 x16 slot ¦ 2x PCIe 3.0 x1

Power

Power supply: 400 W
Power supply input voltage: 230 V
Power supply input frequency: 50 Hz
Power consumption (standby): 1.5 W
Power consumption (off): 0.25 W
80 PLUS certification: 80 PLUS Bronze

Design

Chassis type: Midi Tower
Product colour: Black

Software

Operating system installed: Windows 11 Pro
Compatible operating systems: Windows 10, Windows 11
Pre-installed software: 1-month trial for new Microsoft® 365 customers

Audio

Audio system: High Definition Audio

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 10 - 75%

Weight & dimensions

Width: 180 mm
Depth: 420 mm
Height: 435 mm
Weight: 8 kg

Packaging content

Feature: Mouse included
Feature: Keyboard included
Cables included: AC

Keyboard

Keyboard language: German

Features

Motherboard manufacturer: ASUS PRO B760M-C-CSM ¦ 24-7 ready

Other features

Locale: German
