Supermicro SYS-110P-WTR server

Supermicro SYS-110P-WTR. Processor family: Intel® Xeon® 3000 Sequence. Internal memory type: DDR4-SDRAM. HDD size: 2.5", HDD interface: SATA III. Ethernet LAN. Power supply: 750 W, Redundant power supply (RPS) support. Chassis type: Rack (1U)

Processor

Processor manufacturer: Intel
Processor family: Intel® Xeon® 3000 Sequence
Motherboard chipset: Intel® C621
Feature: Intelligent Platform Management Interface (IPMI) support

Memory

Internal memory type: DDR4-SDRAM
Memory slots: 8
Feature: ECC
Memory clock speed: 3200 MHz
Maximum internal memory: 3 TB

Storage

HDD interface: SATA III
HDD size: 2.5"
Number of HDDs supported: 10
Supported HDD sizes: 2.5"
Feature: RAID support
RAID levels: 0, 1, 5, 10
Feature: Hot-swap
Optical drive type: No

Graphics

Feature: On-board graphics card

Network

LAN controller: Intel® X550
Feature: Ethernet LAN
Ethernet interface type: 10 Gigabit Ethernet

Ports & interfaces

Ethernet LAN (RJ-45) ports: 3
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
VGA (D-Sub) ports quantity: 1
Serial ports quantity: 2

Expansion slots

PCI Express x16 slots: 3

Design

Chassis type: Rack (1U)
Product colour: Black
Feature: Rack mounting

Performance

BIOS type: EEPROM

Software

Operating system installed: No

Power

Feature: Redundant power supply (RPS) support
Power supply: 750 W

Operational conditions

Operating temperature (T-T): 10 - 35 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 8 - 90%
Storage relative humidity (H-H): 5 - 95%

Certificates

Certification: 80 PLUS Platinum Level

Logistics data

Harmonized System (HS) code: 84714100

Weight & dimensions

Width: 437 mm
Depth: 597 mm
Height: 43 mm
Weight: 7.03 kg
Package width: 609.6 mm
Package depth: 812.8 mm
Package height: 203.2 mm
Package weight: 12.2 kg
