Lenovo ThinkCentre M90t Gen 4

Lenovo ThinkCentre M90t Gen 4. Processor family: Intel® Core™ i5, Processor model: i5-13400. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 4400 MHz. Total storage capacity: 512 GB, Storage media: SSD, Card reader integrated, Optical drive type: DVD±RW. On-board graphics card model: Intel UHD Graphics 730. Power supply: 300 W. Chassis type: Tower. Product type: PC. Weight: 6.5 kg. Product colour: Black

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i5
Processor generation: 13th gen Intel® Core™ i5
Processor model: i5-13400
Processor cores: 10
Processor threads: 16
Processor boost frequency: 4.6 GHz
Performance cores: 6
Efficient cores: 4
Performance-core Max Turbo Frequency: 4.6 GHz
Efficient-core Max Turbo Frequency: 3.3 GHz
Performance-core base frequency: 2.5 GHz
Efficient-core base frequency: 1.8 GHz
Processor cache: 20 MB
Processor cache type: Smart Cache
Processor base power: 65 W
Maximum turbo power: 148 W

Memory

Internal memory: 16 GB
Maximum internal memory: 128 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 16 GB
Memory slots: 4x DIMM
Memory clock speed: 4400 MHz

Storage

Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: DVD±RW
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 4.0
Feature: NVMe
SSD form factor: M.2
Feature: Card reader integrated

Graphics

Feature: On-board graphics card
Discrete graphics card model: Not available
On-board GPU manufacturer: Intel
On-board graphics card family: Intel® UHD Graphics
On-board graphics card model: Intel UHD Graphics 730

Performance

Motherboard chipset: Intel Q670
Feature: Trusted Platform Module (TPM)
Product type: PC

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 100,1000 Mbit/s
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: Wi-Fi 6E (802.11ax)
WLAN controller manufacturer: Intel
WLAN controller model: Intel Wi-Fi 6E AX211
Antenna type: 2x2
Feature: Bluetooth
Bluetooth version: 5.1

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
DisplayPorts quantity: 2
HDMI ports quantity: 1
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
Feature: Combo headphone/mic port
Feature: Line-out
Feature: Microphone in

Power

Power supply: 300 W
Power supply input voltage: 100 - 240 V
Power supply input frequency: 50/60 Hz

Design

Chassis type: Tower
Colour name: Black
Volume: 17 L
Feature: Cable lock slot
Cable lock slot type: Kensington
Product colour: Black

Software

Operating system installed: No

Audio

Audio chip: Realtek ALC897Q-CG
Audio system: High Definition Audio
Number of speakers: 1

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Operating altitude: 0 - 3048 m
Non-operating altitude: 0 - 12192 m

Weight & dimensions

Width: 170 mm
Depth: 298 mm
Height: 376 mm
Weight: 6.5 kg

Packaging content

Feature: Mouse included
Mouse connectivity: Wired
Feature: Keyboard included

Certificates

Certification: TCO,RoHS

Keyboard

Keyboard connectivity: Wired
