Lenovo ThinkCentre M75t Gen 5

Lenovo ThinkCentre M75t Gen 5. Processor family: AMD Ryzen™ 7, Processor model: 8700G. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5200 MHz. Total storage capacity: 512 GB, Storage media: SSD, Optical drive type: DVD±RW. On-board graphics card model: AMD Radeon 780M. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 260 W. Chassis type: Tower. Product type: PC. Product colour: Black

Processor

Processor manufacturer: AMD
Processor family: AMD Ryzen™ 7
Processor model: 8700G
Processor cores: 8
Processor threads: 16

Memory

Internal memory: 16 GB
Maximum internal memory: 64 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 16 GB
Memory slots: 2x DIMM
Memory clock speed: 5200 MHz

Storage

Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: DVD±RW
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 4.0
Feature: NVMe
SSD form factor: M.2
Feature: Card reader integrated

Graphics

Feature: On-board graphics card
Discrete graphics card model: Not available
On-board GPU manufacturer: AMD
On-board graphics card family: AMD Radeon
On-board graphics card model: AMD Radeon 780M

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 100,1000 Mbit/s

Ports & interfaces

USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
Feature: Microphone in
Feature: Line-out
Feature: Combo headphone/mic port

Design

Chassis type: Tower
Volume: 13.6 L
Feature: Cable lock slot
Cable lock slot type: Kensington
Product colour: Black

Performance

Audio chip: Realtek ALC623-CG
Audio system: High Definition Audio
Number of speakers: 1
Feature: Trusted Platform Module (TPM)
Product type: PC

Software

Operating system architecture: 64-bit
Operating system language: German
Operating system installed: Windows 11 Pro

Power

Power supply: 260 W
Power supply input voltage: 100 - 240 V
Power supply input frequency: 50/60 Hz

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Operating altitude: 0 - 3048 m
Non-operating altitude: 0 - 12192 m

Certificates

Certification: ENERGY STAR,TCO,EPEAT Gold,RoHS

Weight & dimensions

Width: 145 mm
Depth: 296 mm
Height: 346 mm
Weight: 5.9 kg

Packaging content

Feature: Mouse included
Mouse connectivity: Wired
Feature: Keyboard included
Keyboard connectivity: Wired
