Lenovo Legion T5 30IAS10

Lenovo Legion T5 30IAS10. Processor family: Intel Core Ultra 7, Processor model: 265KF. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory clock speed: 5600 MHz. Total storage capacity: 1 TB, Storage media: SSD. Discrete graphics card model: NVIDIA GeForce RTX 5070 Ti. Operating system installed: Windows 11 Home, Operating system architecture: 64-bit. Power supply: 850 W. Chassis type: Tower. Product type: PC. Weight: 15 kg. Product colour: Black

Processor

Processor manufacturer: Intel
Processor family: Intel Core Ultra 7
Processor generation: Intel Core Ultra (Series 2)
Processor model: 265KF
Processor cores: 20
Processor threads: 20
Processor boost frequency: 5.5 GHz
Performance cores: 8
Efficient cores: 12
Performance-core Max Turbo Frequency: 5.4 GHz
Efficient-core Max Turbo Frequency: 4.6 GHz
Performance-core base frequency: 3.9 GHz
Efficient-core base frequency: 3.3 GHz
Processor cache: 30 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor base power: 125 W
Maximum turbo power: 250 W

Neural processor unit (NPU)

Neural processor unit (NPU): Intel AI Boost
Feature: Sparsity support
Feature: Windows Studio effects support
AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 25 TOPs
NPU performance up to: 13 TOPs

Memory

Internal memory: 32 GB
Maximum internal memory: 64 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 16 GB
Memory slots: 4x DIMM
Memory clock speed: 5600 MHz
Feature: Non-ECC
Memory channels: Dual-channel

Storage

Total storage capacity: 1 TB
Storage media: SSD
Optical drive type: No
Number of storage drives installed: 1
Total SSDs capacity: 1 TB
Number of SSDs installed: 1
SSD capacity: 1 TB
SSD interface: PCI Express 4.0
Feature: NVMe
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)

Graphics

Feature: Discrete graphics card
Discrete GPU manufacturer: NVIDIA
Discrete graphics card model: NVIDIA GeForce RTX 5070 Ti
Discrete graphics card memory: 16 GB
Discrete graphics memory type: GDDR7
Number of discrete graphics cards: 1
On-board graphics card model: Not available

Performance

Market positioning: Gaming
Motherboard chipset: Intel B860
Audio output channels: 5.1 channels
Feature: Password protection
Password protection type: BIOS, HDD
Feature: Trusted Platform Module (TPM)
Product type: PC
Trusted Platform Module (TPM) version: 2.0

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 2500 Mbit/s
LAN controller: Dragon RTL8125BG
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
Antenna type: 2x2
Feature: Bluetooth
Bluetooth version: 5.4

Ports & interfaces

USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Feature: Combo headphone/mic port
Feature: Line-out

Expansion slots

PCI Express x4 (Gen 3.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1

Power

Power supply: 850 W
Power supply input voltage: 100 - 240 V
Power supply input frequency: 50/60 Hz

Design

Chassis type: Tower
Colour name: Eclipse black
Volume: 30 L
Placement supported: Vertical
Feature: Water cooling system
Product colour: Black
Feature: Viewing window

Software

Operating system architecture: 64-bit
Operating system language: German
Operating system installed: Windows 11 Home

Audio

Audio chip: Realtek ALC623
Audio system: High Definition Audio

Operational conditions

Operating temperature (T-T): 5 - 35 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Operating altitude: 0 - 3048 m
Non-operating altitude: 0 - 12192 m

Weight & dimensions

Width: 211 mm
Depth: 490.4 mm
Height: 414 mm
Weight: 15 kg

Packaging data

Package width: 321 mm
Package depth: 596 mm
Package height: 549 mm
Package weight: 17 kg

Certificates

Compliance certificates: RoHS
Certification: RoHS
